Shafts Parameter Optimization Design for Lunar Rover Wheel-Leg Planetary Mechanism

Abstract:

Taking the wheel-legged lunar rover based on double-half-revolution mechanism as a research object, this paper has made a dynamics simulation for the simplified virtual prototype model of lunar rover under several typical road conditions, with the purpose of obtaining the mechanical data of the wheel-leg planetary mechanism shafts. On this basis, this paper established the finite element analysis model of the wheel-leg planetary mechanism shafts, and analyzed their stress by using finite element analysis software ANSYS. Based on ANSYS Parametric Design Language (APDL), the optimization design for the above shafts were done combined with the least-square approximation optimization method. The results show that the optimized shafts not only meet the strength requirement, but also their weights are about 30% lower than the original, which will provide a new and effective way for optimizing the whole wheel-leg structure of lunar rover.

• Periodical: Applied Mechanics and Materials (Volumes 236-237)
• Pages: 1258-1264
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.236-237.1258
• Online since: November 2012
• Authors: Yong Ming Wang, Chuan Hui Bao, Tong Hua Fan
• Keywords: Lunar Rover, Optimization Design, Planetary Mechanism, Shaft, Stress Analysis

References

[1] Yongming Wang, Xiaoliu Yu, Wencheng Tang. A New-type Wheel-legged Lunar Rover and its Mobile Performance Analysis. In: the 2009 International Conference on Mechanical and Electrical Technology, ASME Press, New York, USA, 2009, pp.31-36.

DOI: 10.1115/1.802946.paper6

[2] Xiaoliu Yu, Hui Luo, Wei Xia. Kinematic analysis of the mobile system of Lunar Rover based on Half-rotating mechanism. China Journal of Mechanical Engineering, Vol. 19, 2008(24), pp.2926-2929.

[3] Yongming Wang, Xiaoliu Yu. Double-half-revolution Mechanism Motion Characteristics Analysis and Its Wheel-leg Configuration Design. Chinese Journal of Mechanical Engineering, Vol. 47, 2011(23), pp.44-55.

DOI: 10.3901/jme.2011.23.049

[4] Yongming Wang, Xiaoliu Yu and Wencheng Tang. Kinematics Model of Bionic Wheel-legged Lunar Rover and its Simulation Analysis. In Proc. the Second International Conference on Intelligent Robotics and Applications (ICIRA2009), Springer PRESS, Dec. 16-18, 2009, Singapore, p.2095-(2098).

DOI: 10.1109/iccet.2010.5486293

[5] Peisi Zhong, Jinglin Wang, Mei Liu. Torsion Analysis of Drive Axle based on Finite Element Analysis. Journal of Mechanical Transmission, Vol. 32, 2008(5), pp.88-91.

[6] Weidong Wu, Changli Guo, Hualiang Li. Finite Element Analysis of Shearer Rocker Torque Shaft. Journal of Mechanical Transmission, Vol. 36, 2012(4), pp.84-86.

[7] Liu Feng, Li Hua, Yao Jin. Development of Finite Element Analysis Symstem of Gearer Shaft Parameterization. Journal of Machinery Design and Manufacture, Vol. 18, 2011(11), pp.117-119.
