Five-Phase Half-Controlled Bridge Commutation and Stabilizing Voltage Nd-Fe-B Permanent-Magnet Generator for Light Vehicle

Abstract:

Nd-Fe-B permanent-magnet generator provides DC power for the electrical equipment of light vehicle and charges the battery. The rotor of this generator is constructed by several fastening segments of Nd-Fe-B permanent-magnet material onto the iron core through pole shoes by nonmagnetic bolts with adjacent magnet segments opposed to each other in polarity, i.e. N poles and S poles arrayed alternately. When the rotor rotation, hence the magnetic field rotates, the armature winding cuts the magnetic line and produces electromotive force. The developed five-phase half-controlled bridge commutation and stabilizing voltage adjuster combines both functions of voltage stabilization, commutation, and output direct current (DC) with stable voltage. The instability of output voltage was overcome when the permanent-magnet generator for light vehicle ran at wide range of speed and load.

• Periodical: Applied Mechanics and Materials (Volumes 236-237)
• Pages: 1280-1285
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.236-237.1280
• Online since: November 2012
• Authors: Jian Long Hu, Xue Yi Zhang, Wen Fu Zhang
• Keywords: Commutation Stabilization, Generator, Light Vehicle, Nd-Fe-B Permanent-Magnet, Voltage Stabilization

References

[1] Zhnag Xueyi, Wang Yalin, Wang Jianshe, Prospect on Permanent-magnet Generator of Vehicle, J. Micromotors Servo Technique. 38(5) (2005) 70-71.

[2] Huang Yanyun, A Summary of Automotive Permanent-magnet Generator, J. Small & Special Electrical Machines. 4 (2000)25-28.

[3] Ma Youliang, Ding Weidong, Automobile Electrical and Electronic Systems, China Machine Press, Beijing, (2003).

[4] Tang Renyuan, Modern Permanent Magnet Machines Theory and Design, China Machine Press, Beijing, (2010).

[5] Chen Junfeng, Permanent Magnet Machines (II), China Machine Press, Beijing, (1983).

[6] Zhang Xueyi, Shi Liwei, An Analysis on the Voltage Stability of 42V Automotive Generator with Nd-Fe-B Permanent-magnet Rotor, J. Automotive Engineering. 33(11)(2011)994-997.

DOI: 10.1109/cmce.2010.5610232

[7] Qin Zenghuang, Electrotechnics (Book2), Higher Education Press, Beijing, (2000).

[8] Tian Hanmin, Magnetic Materials, Tsinghua University Press, Beijing, (2001).

[9] JB/T8582. 6—2011, Machinery Industry Standard of People's Republic of China, Farm transporter, Generator.
