Fault Diagnosis Mechanism Based on FTA and Bayesian for Large-Scale CNC Equipments

Abstract:

In view of the disadvantage of current FAT-based fault diagnosis method in large-scale complicated system, fault diagnosis method of heavy NC machine based on FTA and Bayesian is discussed. Firstly, building fault trees with the help of reachability matrix, and to set the determinate conditions at every node of fault tree combining FTA with rule reasoning, the minimum cut set of fault reasons are determined as a result of step by step screening fault tree from top-down; Secondly, Bayesian method is integrated into the fault tree diagnostic method to calculate the posterior probability triggered by each fault tree in order to locate the fault tree where the fault had occurred and ensure high efficiency of fault diagnosis; Finally, B/S based intelligent fault diagnosis system for large-scale CNC equipments is developed, and the feasibility and efficiency of this method are proved in an example of fault diagnosis of Φ 160 NC boring and milling machine.

• Periodical: Applied Mechanics and Materials (Volumes 236-237)
• Pages: 474-479
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.236-237.474
• Online since: November 2012
• Authors: Jin Fei Liu, Ming Chen, Ying Lei Li
• Keywords: Bayesian Algorithm, FAT, Fault Diagnosis System, Fault Tree, Reachability Matrix

References

[1] Jing X, Hong YJ. Analysis on system reliability and availability. Beijing: Academic Press, (2007).

[2] Bian MM, Shi j, Wang SP. FTA-based fault diagnose expert system for hydraulic equipments. Proceedings of 2011 International Conference on Fluid Power and Mechatronics. 26(2011), 959-963.

DOI: 10.1109/fpm.2011.6045901

[3] Aliee, H.  Fault tree analysis using stochastic logic: A reliable and high speed computing. Proceedings of 2011 Reliability and Maintainability Symposium (RAMS). 2011, 1-6.

DOI: 10.1109/rams.2011.5754466

[4] Chiacchio F, Compagno L, DUrso D, et al. Dynamic fault trees resolution: A conscious trade-off between analytical and simulative approaches. Reliability Engineering & System Safety, 2011, vol. 96(11): 1515-1526.

DOI: 10.1016/j.ress.2011.06.014

[5] Bian XQ , Mou CH, Yan ZP. Reliability analysis of AUV based on fuzzy fault tree. 2009 IEEE International Conference on Mechanics and Automation, 2009, vol. 1 (7): 438-442.

DOI: 10.1109/icma.2009.5246655

[6] Liu Sheng, Weng Zhen-ping, Li Gao-yun. Research on fault diagnosis for ship course control System. International Conference on Mechanics and Automation, 2009, vol. 1(7): 617-621.

DOI: 10.1109/icma.2009.5245034

[7] Zhou ZB, Ma CQ, Zhou JL et al. Dynamic fault tree analysis based on dynamic Bayesian networks. Systems Engineering-Theory & Practice, 2008, vol. 2: 35-42.

[8] Tao YJ, Dong DC, Ren P. An improved method for system fault diagnosis using fault tree analysis. Journal of Harbin Institute of Technology, 2010, vol. 1: 143-147.

[9] An CL. An application of fault tree theory in fault diagnosis system. Missiles and Space Vehicles, 2009, vol. 299 (1): 48-51.

[10] Xu SN, Zhang YF, Yi H. Intelligent fault diagnosis method based on fault tree . Journal of Shanghai Jiaotong University, 2008, vol. 42 (8): 1372-1375.

[11] Zhang Q, Liao J, Wu JJ. Design of diagnostic expert system for electronic system of general equipment based on FTA. Acta Armamentarii, 2008, vol. 29 (2): 174-177.
