Stress Distribution in Reverse-Bent Bonded Joint

Abstract:

Adhesively bonding technology is used increasingly by the automotive and aerospace industries. The design of reverse-bent joint is effective way for improving the bonded joint performance. The influence of preformed angle on the stress distribution of the adhesive-adherend interface is studied in this paper using finite element analysis (FEA). By comparing the results of the FEA for reverse-bent joints with different preformed angle, it can be seen that the preformed angle not only have significant influence on the stress distribution of overlap section, but also changes stress concentration at the spew fillet of bonded joint. The results also indicate that there is a best value of preformed angle in which the reverse-bent bonded joint has the best performance.

You might also be interested in these eBooks

Advanced Technology for Manufacturing Systems and Industry

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 236-237)

Pages:

48-51

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.236-237.48

Citation:

Cite this paper

Online since:

November 2012

Authors:

Yong Tang, Xiao Cong He, Jun Chao Zheng, Kai Zeng, Yan Fang Ding, Yue Bo Hu

Keywords:

Finite Element Analysis (FEA), Reverse-Bent Joint, Stress Concentration, Stress Distribution

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] X. He, A review of finite element analysis of adhesively bonded joints, Int. J. Adhes Adhes. 31(2011) 248-264.

Google Scholar

[2] X. He, Stress distribution in the cantilevered single-lap adhesive joint, Advanced Materials Research (2010) 936-939.

DOI: 10.4028/www.scientific.net/amr.179-180.936

Google Scholar

[3] A.S. McLaren, I. MacInnes, The influence on the stress distribution in an adhesive lap joint of bending of the adhering sheets, Br.J. Appl Phys. 9(1958)72-77.

DOI: 10.1088/0508-3443/9/2/306

Google Scholar

[4] G. Fessel, J. G. Broughton, N. A. Fellows, J. F. Durodola, Evaluation of different lap-shear joint geometries for automotive applications, Int.J. Adhes Adhes. 27(2007) 574-583.

DOI: 10.1016/j.ijadhadh.2006.09.016

Google Scholar

[5] Z.M. Yan, M. You, X.L. Zheng, M.S. Zhang, Influence of Elastic Modulus of Adhesive on the Stress and Strength of Joint with Recessing, Ch.J. Aeron . 28(2007)253-256.

Google Scholar

[6] Q. Zeng, C.T. Sun, Aiaa, New design of a bonded lap joint. J. AIAA. 39(2001)1991-(1996).

DOI: 10.2514/3.14959

Google Scholar

[7] G.C. Sih, Some basic problems in fracture mechanics and new concepts, Engin Fract Mecha. 5(1973)365-377.

DOI: 10.1016/0013-7944(73)90027-1

Google Scholar
