Rhombus Cradle System Checking Computation of Jinqinggang Bridge

Abstract:

In order to be sure the safety of rhombus cradle system during the concretes cantilever cast-in-place construction, the paper makes use of probabilistic limit state method, and carries out the checking computation. According to the rhombus cradle design drawings of the Jinqinggang bridge and the actual load case, the analytical model is founded through the finite element analysis software MIDAS/CIVIL. The results show that stress of all parts of the rhombus cradle system and the concrete local pressure stress is less than the corresponding material design value, and the safety factor of anchor rod tensile stress is less than 2.0 which should be strengthened, and the deformation of the steel moulding plate is less than 20mm.

• Periodical: Applied Mechanics and Materials (Volume 238)
• Pages: 689-693
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.238.689
• Online since: November 2012
• Authors: Shi Ming Liu, Zu Lin Yang, Hui Zhao
• Keywords: Bridge Engineering, Checking Computation, Prestressed Concrete Box Girder, Probabilistic Limit State, Rhombus Cradle System

References

[1] Y. Xu, Y. Guo and F. Song: East China Highway, No. 6 (2010), pp.10-14.

[2] Z. Wu: Guangdong Building Materials, No. 11 (2010), pp.63-64.

[3] Y. Ji: The Bridge Construction, No. 4 (2007), pp.46-48.

[4] JTG/T F50-2011: Technical Specification for Construction of Highway Bridge and Culvert (China Communications Press, Beijing, 2011).

[5] GB 50017-2003: Code for Design of Steel Structures (China Building Industry Press, Beijing, 2003).
