Checking Computation for Bracket Structure of Jinqinggang Bridge

Abstract:

In order to ensure the safety of bracket structure during the cast-in-place construction of No.0 and No.1 piece concretes, this paper makes use of probabilistic limit state method to do the checking computation. According to the design drawings of bracket structure of the Jinqinggang bridge and the actual load case, the analytical model is founded by the finite element analysis software MIDAS/CIVIL. The results show that the stresses of all parts of the bracket structure including the concrete local compressive stress and the tensile stress of embedded steel bar are less than the allowed value of corresponding materials, but the deformation of the steel moulding plate is larger than standard allowance value. The weld joint between upper chord and slanting pole with embedded steel plate satisfies the design requirement.

• Periodical: Applied Mechanics and Materials (Volume 238)
• Pages: 701-704
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.238.701
• Online since: November 2012
• Authors: Shi Ming Liu, Hui Zhao, Zu Lin Yang
• Keywords: Bracket Structure, Bridge Engineering, Checking Computation, Prestressed Concrete Box Girder, Probabilistic Limit State

References

[1] Z. Lin, Urban Roads Bridges & Flood Control, 8 (2010) 62-66.

[2] W. Zhang, Railway Engineering, 3 (2007) 25-26.

[3] J. Wang, Y. Li, X. Tong, Qinghai Transportation Science and Technology, Supp. (2010) 55-57.

[4] JTG/T F50-2011, Technical Specification for Construction of Highway Bridge and Culvert, China Communications Press, Beijing, 2011.

[5] GB 50017-2003, Code for Design of Steel Structures, China Building Industry Press, Beijing, 2003.
