MPPT of Two-Peak PV System Combined the Hysteresis Comparison Method with Incremental Conductance

Abstract:

Due to the different PV modules and external conditions, large-scale photovoltaic power plants often show a multi-peak PV characteristics. But the traditional MPPT methods is only for single-peak P-V curve to strike a maximum power point. So we need to improve the conventional MPPT methods. In the MATLAB/Simulink environment, we combined the Hysteresis Comparison Method with Incremental Conductance to build the S-function to create a simulation model obtaining the maximum power point power, voltage and current. In the same simulation system the traditional Incremental Conductance was used to obtain the maximum power, voltage and current which compare with the maximum power, voltage and current which obtained by the proposed method . The results of simulation illustrated the effectiveness of the proposed method .

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 123-128
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.123
• Online since: December 2012
• Authors: Dan Wu, Jing Xue, Ting Ting Li
• Keywords: MATLAB, Maximum Power Point (MPP), Two-Peaks

References

[1] Yuwen Zhao, DachengWu, SichengWang: Report China PV industry development(2006-2007).

[2] Deng Yi: Complex circuits for IGBT model and modeling of large photovoltaic arrays[D]. Beijing: Tsinghua University, 2010: 23-52(in Chinese).

[3] Chen Jian: Solar photovoltaic maximum power point tracking technology[D]. Beijing: Tsinghua University, 2010(in Chinese).

[4] Chihchiang Hua, Jongrong Lin, Chihming Shen: Implementation of a DSP-controlled photovoltaic system with peak power tracking[J]. IEEE Transactions on Industrial Electronics, 1998, 45(1): 90-107.

DOI: 10.1109/41.661310

[5] Leem C S: An automated fault diagnosis for manufacturing process monitoring and control[J]. International Journal of Modeling and Simulation, 1996, 16(4): 200-208.

[6] Mao Meiqin, Yu Shijie, Su Jianhui: Versatile Matlab Simulation Model for Photovoltaic Array with MPPT Function[J]. Acta Simulata Systematica Sinica, 2005, 17(5): 1248-1251.

[7] LIU Bangyin, DUAN Shanxu, LIU Fei: Analysis and improvement of maximum power point tracking algorithm based on incremental conductance method for photo valtaic array[C]. PEDS 7th International Conference on Power Electronics and Drive Systems. 2007: 637-641.

DOI: 10.1109/peds.2007.4487768

[8] Long Tengfei, Ding Xuanhao, Cai Ruhua: Photovoltaic power system output characteristic and the theoretic analysis to the three p-point comparing on MPPT algorithm[J]. Energy Conversation, 2007, 26(8): 14-17.
