Analysis on the Shielding Effectiveness of Metallic Box with Apertures Based on FDTD

Abstract:

The SE of the shield is reduced greatly for the existence of aperture in the electronic equipment design process. The shielding characteristic of slot apertures and pore array are analyzed with the method of FDTD, and also put forward the way to increase the SE of the shield. The metallic box of some electronic equipment has been redesigned by applying the conclusion. Practice shows that FDTD method is a fast and efficient method for an aperture question, and the analysis conclusion can be helpful to the electromagnetic shielding design of the metallic box with apertures.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 283-286
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.283
• Online since: December 2012
• Authors: Yin Han Gao, Jun Jie Gu, Kai Yu Yang, Hang Zhang
• Keywords: Aperture, FDTD, Pore Array, Shielding Effectiveness

References

[1] Yee K: IEEE Trans. Antennas Propagate volume Vol. 14 (1966) , p.302.

[2] SO-I: IEEE Microwave and Guided Wave Let-ters Vol. 8 (1998), p.152.

[3] Shan Zhou, Zhenxin Zhang and Huachun Shen: Electronic Quality Vol. 9 (2008), p.80, in Chinese.

[4] Tao Liu, Lei Zhang, Liping Cao and Chen Chen: Electronic Component & Device Application Vol. 12 (2010), p.90, in Chinese.

[5] Kuangang Fan. Research on the Electromagnetic Radiation for Lgnition System in Car Engine (Jilin University Press, Jinlin 2010), in Chinese.

[6] Yinhan Gao, Kuangang Fan, Wenyong Jia and Yan Zhang: World Sci-tech R & D Vol. 31 (2009), p.442, in Chinese.

[7] Xiangyu Mao, Pingan Du and Baolin Nie: Journal of System Simulation Vol. 23 (2009) , p.7493, in Chinese.

[8] B. J. Peter: IEEE Transactions on Microwave Theory and Techniques M1T-35 (S0018-9480) Vol. 35 (1987), p.370.
