Study on Load Spectrum Correlation between Service Roads and Proving Ground Roads Based on Spindle Wheel Forces

Abstract:

The spindle wheel forces load spectrums of certain car were collected on typical service roads and proving ground roads. Rain-flow matrixes of wheel forces in target service roads and proving ground roads were analyzed based on measured load spectrums with analysis software. Then different roads of proving ground were combined to simulate target service roads with load equivalent analysis method based on rain-flow matrixes. The damages were compared between target service roads and combined roads in proving ground. The results show that the combined roads in proving ground can reflect the true damage of the target service roads.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 685-689
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.685
• Online since: December 2012
• Authors: Yu Dong Hu, Hong Zhou, Gang Xu, Chao Guan, Ying Xi Wu
• Keywords: Correlation, Load Spectrum, Proving Ground, Rain-Flow Matrix, Service Road

References

[1] LMS International. LMS TecWare Documentation, (1999)

[2] Wei Peng. Study on loading spectra correlation of EVP proving ground to typical roadsand fatigue life digital prediction of car's rear axel. Shanghai: Tongji University, (2004)

[3] Jianguo Wu, Hong Zhou, Donghua Chen, Chuanfeng Wei. Study on Road Equivalent Simulation Based on Loading Spectrums in Customer Road and Proving Ground. Automotive Technology, (2007)

[4] Xiaopneg Zhao, Ding Jiang, Qiang Zhang, et al. Application of Rain-flow Counting Method in the Analysis of Load Spectrum[J]. Science & Technology, 2009, 27 (3): 68-73
