A Numerical Controlled Constant Current Source Based on Power MOSFET

Abstract:

Supercapacitor is widely used in high power energy storage device, and its charge and discharge properties decide the energy storage devices of important performance indicators. In this paper, in order to research the charging performance of supercapacitors, a constant current test system which is based on microcontroller was designed. The system use a program-controlled constant current source which focuses on high-power MOSFET in accordance with the current data gotten from the sampling circuit, adjust the output current by PID algorithm, and thereby enhance the controlling precision of the output of the constant current. Under the combined control between upper machine and lower machine, the test system can map out potential function curve following time-varying, so that the supercapacitor’s charge process implement visualization. The result which tests the supercapacitor shows that the circuit has a simple structure and the current is very stable, which can be applied to all kinds of energy storage device which requires high current for charge and property test.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 1859-1862
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.1859
• Online since: December 2012
• Authors: Kai Wang, Yuan Gao, Yu Fan
• Keywords: Constant Current Source, Stable, Super-Capacitor (SC)

References

[1] T.A. Smith, Using Supercapacitors to improve battery performance., Power Electronics Specialists Conference. Sydney, pp.124-128, (2002).

[2] Zhang Li, Song Jin-yan, Zou Ji-yan, and Wang Ning, High Voltage Super-capacitors for Energy Storage Devices Applications, Proc. 12th Inter. EML Symp. Victoria, pp.83-87, (2008).

[3] Wu Mao-cheng. Design of a high-presion wide range constant current source, Electrical Measuremen&Instrumentation, vol. 48(1), pp.64-66, (2011).

[4] Liu Wei-min, Zhang Li, Song Jin-yan. A CCSC Testing the Performance of Supercapacitor, Chinese Journal of Scientific Instrument, vol. 27(6), pp.928-929, (2006).

[5] Zhang Li, Yu Peng, Zou Ji-yan. The Research of Programmable Test Equipment for Invariable Power Discharge, South Univ, vol. 38(7), pp.1164-1168, (2007).

[6] Rong Jun, Zhang Min, Li Yi-ming. The Technology study of Constant Current Source Based on SCM, Chinese Journal of Election Devices, vol. 34(1), pp.63-65, (2011).

[7] Qi Ying-chuan, Hu Rong-qiang, Wang Jie. Advance Technology of Electrical Engineering and Energy, Advanced Technology of Electrical Engineering and Energy, vol, 30(1), pp.52-56, (2011).
