Preliminary Experiment of CFRP Displacement Direct Measurement with Eddy Current Sensor

Abstract:

Displacement and vibration can always be found during the applications of CFRP ( carbon fibe reforced polymer). So it’s quite meaningful to measure the displacement of CFRP directly. Eddy current sensor is a promising tool for this measurement. CFRP presents great heterogeneity and high anisotropy in electromagnetic properties. At the same time, it has been proved that CFRP has quite weak conductivity. All of these means great challenge to the use of eddy current sensor, as the sensitivity would be much lower compared with traditional material such as aluminum. Many experiments have been carried out on the experimental platform self-developed in laboratory. A simplified eddy current sensor with adjustable resonant circuits was designed. Two different kinds of CFRP were used as specimens. For purposes of comparison, an aluminum ingot sample was also tested. A number of experimental data and results have been achieved. It is shown that the sensitivity will be highly improved by adjusting the divider resistance and the actuation frequency.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 3-8
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.3
• Online since: December 2012
• Authors: Lei Jiang, Xiao Zhang Zhang, Yu Jie Bai, Chang Liang Tang
• Keywords: Carbon Fiber Reinforced Polymer/Plastic (CFRP), Displacement Measurement, Eddy Current

References

[1] G. Megali, D. Pellicanµo, M. Cacciola, S. Calcagno,M. Versaci and F. C. Morabito, EC modeling and enhancement signals in CFRP inspection, Progress In Electromagnetics Research M, 14 (2010) 45-60.

DOI: 10.2528/pierm10072705

[2] Z.G. Tan, L.Y. Wang, Detection technology of eddy current, first ed., Atomic Energy Press, Beijing, (1986).

[3] Jerome Tzeng, Ryan Emerson, Paul Moy, Composite flywheel development for energy storage, ARL-TR-3388, (2005).

DOI: 10.21236/ada431734

[4] Prakash R., Owston C. N, Eddy-current method for the determination of lay-up order in cross-plied CFRP laminates, Composites, 7 (2) (1976) 88-92.

DOI: 10.1016/0010-4361(76)90018-5

[5] Owston, C. N, Eddy current methods for the examination of current fibre reinforced epoxy resins, Materials Evaluation, 34 (11) (1976) 237-244.

[6] Menana H., Féliachi M., Modeling the response of a rotating eddy current sensor for the characterization of carbon fiber reinforced composites, EP Applied Physics, 52 (2) (2010).

DOI: 10.1051/epjap/2010079

[7] Schulze, Martin H., Heuer Henning, Küttner Martin, Meyendorf Norbert, High-resolution eddy current sensor system for quality assessment of carbon fiber materials, Microsystem Technologies, 16 (5) (2010) 791-797.

DOI: 10.1007/s00542-010-1047-3

[8] Schulze Martin H., Meyendorf Norbert, Heuer Henning, Analysis techniques for eddy current imaging of carbon fiber materials, Materialpruefung/Materials Testing, 52 (9) (2010) 603-609.

DOI: 10.3139/120.110167

[9] L. Cheng, G-Y Tian, Surface crack detection for carbon fiber reinforced plastic (CFRP) materials using pulsed eddy current thermography, IEEE Sensors Journal, 11(12) (2011) 3261-3268.

DOI: 10.1109/jsen.2011.2157492
