Mechanism Design of De-Icing Robot and its Auxiliary Equipment for High-Voltage Transmission Lines

Abstract:

Based on the present study of the de-icing robot for high-voltage transmission lines, a new kind of de-icing robot for transmission lines and its auxiliary equipment for hoisting and lowering the robot are designed. The operation of the robot mainly includes four modules: walking module, de-icing module, obstacle negotiation module and hoisting-and-lowering module. The robot’s walking is driven by the rolling of the idler wheel, the de-icing is realized by combination of knocking and cutting, the obstacle negotiation part relies on the rotary telescopic arm’s coordinate crisscross motion with the box, and the motion of the hoisting-and-lowering device is based on the fixed pulley principle. The de-icing tests in laboratory and field demonstrate that this new kind of robot can walk autonomously and de-icing well on the transmission line, it has good de-icing effects, and the auxiliary equipment for hoisting and lowering the robot is safe and feasible.

• Periodical: Applied Mechanics and Materials (Volumes 246-247)
• Pages: 960-965
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.246-247.960
• Online since: December 2012
• Authors: Yi Zhang, Jun Han, Da Lin Zhu, Fu Zhou Ai
• Keywords: De-Icing, Hoisting, Lowering, Obstacle Negotiation, Robot, Transmission Line

References

[1] Zhang Haixia, Sun Wei, Miao Siyi. Model Building and Motion Control of De-icing Robot on Voltage Transmission Line [J]. Computer Engineering and Applications, 2010, 46(10): P190-192.

[2] Wang Cong, Sun Wei. Line-grasping Control for the Deicing Robot on High Voltage Transmission Line [J]. Chinese Journal of Mechanical Engineering, 2011, 47(9): P 8-15.

DOI: 10.3901/jme.2011.09.008

[3] Wang Jidai et al. Design of a Novel Mechanical Structure of De-icing Robot for Power Transmission Lines [J]. Machinery Design & Manufacture, 2011, 5(5): P62-64.

[4] Wang Chao, Wei Shimin, Liao Qizheng. Design of a Robot for Deicing High Voltage Transmission Lines [J]. Mechanical Engineering & Automation, 2010, 2 (1): P148 -149.

[5] Hou Wenqi et al. Design of Mechanical Configuration and Dynamics Simulation of De-icing Robot for Power Transmission Lines [J]. Machinery & Electronics, 2009, (10): P52-55.

[6] Geng Liang. Research of Manipulator Obstacle Control for Transmission Line De-icing Robot [D]. Lanzhou University of Technology: (2010).

[7] Zhang Yi et al. Development and Dynamics Simulation of De-icing Robot for Overhead Power Transmission Lines [J]. Water Resources and Power, 2011, 29 (3): P162 -165.

[8] Sawada J, Kusumoto K, Munakata T. A Mobile Robot for Inspection of Power Transmission Lines. IEEE Transactions on Power Delivery, 1991, 61, 6(1): P309-315.

DOI: 10.1109/61.103753
