Characteristics of Self-Synchronization of Dual-Rotors System

Abstract:

The characteristics of the self-synchronization in the offset self-synchronous system are put forward. In the paper, based on Lagrange principle, a dynamic model is derived to give its electromechanical-coupling model, which is provided with many variable no-linear characters. A serious of the practical phenomena in the transition process of the system is reasonably explained using the numerical solution simulation, and the variations rules of each parameter in the system are discussed at several types of the typical status. Finally the characteristics of the self-synchronization in the system are generated under the action of the electromechanical coupling. The visually processes are shown in the simulation results, for which the conventional mechanic models are unavailable to explain quantitatively, in which the vibration machines implement fully the transition from asynchronous to synchronous state or from one type of synchronous state to other type. It is fully verified that the system is with the self-healing synchronous ability, and the synchronous movement rules in the electromechanical coupling system are also revealed. For its research not only it is useful to explore the electromechanical coupling model of the offset self-synchronous system, but also it is in-depth to study synchronous motion rules of the self-synchronous system, and it is of the theoretical and practical importance.

• Periodical: Applied Mechanics and Materials (Volumes 249-250)
• Pages: 366-371
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.249-250.366
• Online since: December 2012
• Authors: Nan Zhang
• Keywords: Electromechanical Coupling, Nonlinear Vibration, Self-Synchronization

References

[1] M.G. Rosenblum et al., Phase synchronization of chaotic oscillators. Physical Review Letters. 76(1996), 1804-1807.

DOI: 10.1103/physrevlett.76.1804

[2] B.C. Wen. Study on Regular pattern of motion of self-synchronus vibrating machines with deviated vibrators. Journal of Applied Mechanincs, 2(1985), 23-36. (in Chinese).

[3] T. X. Zhang, Study on synchronization of two eccentric rotors driven by hydraulic motors in one vibrating systems. Shock and Vibration, 4(1997), 305-310. (in Chinese).

DOI: 10.1155/1997/319635

[4] W. L. Xiong, Mechanism of electromechanical-coupling on self-synchronous vibration and vibratory synchronization transmission. Journal of Vibration Engineering, 13(2000), 325-331. (in Chinese).

[5] Y.J. Hou and G.X. Yan Electromechanical-coupling mechanism of self-synchronous vibrating system with three-motor-driving. Journal of Vibration Engineering, 19(2006), 354-358. (in Chinese).
