A Numerical Study on the Influence of Grooves on Heat Transfer Performance of Wet Clutch

Abstract:

In order to evaluate the efficacy of grooves on cooling performance of wet clutch, a numerical analysis based on the computational fluid dynamics (CFD) code FLUENT is presented in this study. This analysis is based on the numerical solution of the three-dimensional Navier-Stokes equation, coupled with the energy equation in the flow and the heat conduction equations in the friction material and the core disk. The turbulence characteristics were predicted using RNGk-ε model. The flow field and temperature distributions in radial grooves are obtained. It is shown that radial grooves possess the highest heat exchange performance at the entrance and is not linear distribution in the radial direction and cooling oil flow has a little effect on the highest temperature of friction plate. With the developed analysis method, it is possible to easily and quickly investigate the heat transfer behaviour of wet cluth with groove patterns.

• Periodical: Applied Mechanics and Materials (Volumes 249-250)
• Pages: 517-522
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.249-250.517
• Online since: December 2012
• Authors: Yu Long Lei, Jie Tao Wen, Xing Zhong Li, Cheng Yang
• Keywords: Computational Fluid Dynamics (CFD), Grooves, Heat Transfer, Numerical Simulation, Wet Clutch

References

[1] A.E. Anderson, R.A. Knapp, Hot spotting in automotive friction systems, Wear. 135 (1990) 319–337.

DOI: 10.1016/0043-1648(90)90034-8

[2] P. Zagrodzki, Numerical analysis of temperature fields and thermal stresses in the friction discs of a multidisc wet clutch, Wear. 101 (1985)255.

DOI: 10.1016/0043-1648(85)90080-8

[3] Yang, Y., Lam, R. C., Chen, Y. F., and Yabe, H., Modeling of Heat Transfer and Fluid Hydrodynamics for a Multidisk Wet Clutch, 1995, SAE Paper No. 950898.

DOI: 10.4271/950898

[4] Natsumeda, S., and Miyoshi, T., Numerical Simulation of Engagement of Paper Based Wet Clutch Facing, ASME J. Tribol. 116(1994)232–237.

DOI: 10.1115/1.2927201

[5] S. Natsumeda, T. Miyoshi, Numerical simulation of engagement of paper based wet clutch facing, ASME J. Tribol. 116 (1994) 232.

DOI: 10.1115/1.2927201

[6] Chrisope, D.R., Stinnett, D.W., Hartley, R.J., Friction retention and thermal decomposition of fluid additives in wet clutch system. Proceedings of the TAE Tribology Colloquium Esslingen, Germany (1992).

[7] W.Y.D. Yuen, Heat conduction in sliding solids, Int. J. Heat Mass Transfer. 31 (3) (1988) 637.

DOI: 10.1016/0017-9310(88)90045-2
