The Design of AT-Cut Multiple-Electrode Quartz Crystal Resonator and the Research of its Oscillation Stability and Force-Frequency Property

Abstract:

According to the oscillation characteristics of the quartz crystal resonator and the relationship between its force sensitive property and stress distribution on crystal plate, the single-base multiple-electrode quartz crystal resonator is designed. The oscillation stability of the resonator with this structure is tested by using crystal frequency stability tester. The force-frequency property of the resonators formed by electrodes on different positions of the new structure crystal plate is studied by adding radial force on it. The experimental results show that when the new structure quartz crystal resonator works driven by integrated chip, its oscillation frequency stability can reach 10-8, with the electrode thickness increasing, the oscillation stability of the resonators improves. The force-frequency property of the resonator on the different position of the same crystal plate is different, and the force-frequency coefficient has an obvious difference. The total force-frequency coefficient of the newly designed single-base three-electrode quartz crystal resonator can reach 338.8Hz/N by using mix frequency process.

You might also be interested in these eBooks

Advanced Research on Applied Mechanics and Manufacturing System

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 252)

Pages:

77-80

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.252.77

Citation:

Cite this paper

Online since:

December 2012

Authors:

You Bin Sun, Wen Jie Tian, Qing Jiang Zhao, Bai Yang Lan

Keywords:

AT Cut Multiple-Electrode Quartz Crystal Resonator, Force-Frequency Property, Oscillation Stability

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] ZHANG-Bo, FU Wei-ling, TANG Wan-li. Development of Piezoelectric Quartz Crystal Biosensor's Application Research. Journal of Transducer Technology. 2002, 5,P. 58-61.

Google Scholar

[2] Guanping Feng, Jingsong wang. The Stress-frequency Effect of Quartz Crystal Resonators and Its Applications. Journal of Tsinghua University (Sci & Tech). 1998, Vol. 38(8) ,P. 101-103.

Google Scholar

[3] Tian Wenjie, Li Yuehong, Huo Jing, Tian Shuang, Tian Qiang. Research on Same-base Common-mode Rejection Quartz Crystal Resonator. Chinese Journal of Scientific Instrument. 2008, 8,P. 1650-1653.

Google Scholar

[4] B.B. Manob. Piezoelectric Resonant Sensor. (Shanchen Weng). Beijing: national defense industrial publishing company, 1984,P. 35-36.

Google Scholar
