The Control of Building Load on the Shallow Foundations Close to the Metro Tunnel

Abstract:

Considering the feature of soil layers and surrounding architectures in line 1 of Ningbo metro, finite element method is used to analyze the impact of displacement of existing shield-tunnel, which comes from the building load on the shallow foundations closed to the metro tunnel. Then, the effect feature of upper load of shallow foundation on metro tunnel is got. It is shown that both the horizontal displacement and the vertical displacement of shallow foundations decrease with increase of the horizontal projection distance between loading position and tunnel, and the reducing magnitude of the vertical displacement is significantly larger than that of the horizontal displacement. Accordingly, it is proposed that both the horizontal displacement and the vertical displacement should be controlled within 10mm when the loading width is approximately 10m, and it can be regarded as the controlling distance of the building load of metro tunnel.

• Periodical: Applied Mechanics and Materials (Volumes 256-259)
• Pages: 1287-1290
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.256-259.1287
• Online since: December 2012
• Authors: Chen Bin, Jun Neng Ye
• Keywords: Building Load, Loading Levels, Shallow Foundation, Shield-Tunnel

References

[1] LOU Xiaoming, LIU Jianhang. Monitoring and Analysis of Influence of Pile Foundation under High-rise Buildings on Adjacent Tunnel[J]. Journal of Tongji University(Natural Science), 2003,31(9): 1014-1018. (in Chinese)

[2] YANG Xiaojie, DENG Feihuang, NIE Wen, et al. Study on effect of metro tunneling on carrying capacity of pile foundation[J]. Chinese Journal of Rock Mechanics and Engineering, 2006,25(6):12901295.(in Chinese)

[3] CUI Guangyao, WANG Mingnian, LU Junfu, et al. Adjacent Pile Foundation Construction Displacement Control Technology of Passenger Dedicated Line Jichang Road Tunnel Crossing under Viaducts[J]. China Rail Science, 2011,32(3): 68-73.(in Chinese)

[4] ZHANG Zhiqiang, HE Chuan. Research on mechanics behavior of a shield tunnel construction in metro adjacent to existing pile foundation[J]. Journal of The China Railway Society, 2003,25(1): 92-95. (in Chinese)

[5] YANG Yong-ping, ZHOU Shunhua, ZHUANG Li. Numerical Simulation Analysis on Influence of Shield Excavation Tunnel Close to the Piles of a Building [J]. Cninese Journal of underground space and engineering, 2006, 2(4): 561-565.

[6] JIANG Xin-liang  ZHAO Zhi-min  LI Yuan. Dynamic Simulation of the Effects of Shield Tunneling in Tianjin Subway Project on Neighboring Job Facilities [J]. Journal of Tianjin university, 2006,39(2): 188-193.

[7] LIU Bing,YE Jingbing,YU Xiaolin. Analysis for Influence on Nearby Existing MTR Tunnel during Excavation Construction[J]. Science technology and engeering, 2009, 9 (23): 7222–7225.
