Time-Dependent Temperature Distribution of Sheets in the Stage of Storing

Abstract:

Obtaining a uniform thickness of the final product using thermoforming is difficult, and the thickness distribution depends strongly on the distribution of the sheet temperature. In this paper, the time-dependent temperature distribution of the total sheets in the stage of storing was studied using the analysis code which has been verified based on the experimental data. It was found out that the time for storing should be managed for decreasing the temperature difference between the sheets. The time-dependent temperature distribution of the total sheets and the method for analysis in this study will be used to improve the quality of the final products.

• Periodical: Applied Mechanics and Materials (Volumes 26-28)
• Pages: 1137-1141
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.26-28.1137
• Online since: June 2010
• Authors: Zhen Zhe Li, Rui Jiang, Dong Ji Xuan, Tai Hong Cheng, Seoung Yun Seol, Yun De Shen
• Keywords: Heat Transfer, Numerical Method, Thermoforming

References

[1] M. K. Warby, J. R. Whiteman, W. G. Jiang, P. Warwick and T. Wright: Mathematics and Computers in Simulation, Vol. 61(2003), p.209.

DOI: 10.1016/s0378-4754(02)00077-0

[2] J. E. Cunningham, P. F. Monaghan and M. T. Brogan : Applied Science and Manufacturing Vol. 29(1998), p.51.

[3] J. L. Throne: Technology of Thermoforming, Hanser Publishers, Munich, New York, USA, (1987) 10-3 10-2 10-1 100 101 102 103.

[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] time(h) Temperature ( oC ).

[24] 48 72 96 100 101 102 103.

[50] [52] [54] [56] [58] [60] [62] [64] [66] time(h) Temperature ( oC ) Center Surface.

[24] 48 72 96.

[4] M. T. Brogan and P. F. Monaghan: Applied Science and Manufacturing, Vol. 27(1995), p.301.

[5] Z. M. Zhang and Y. H. Zhou: Int. J. of Thermophysics, Vol. 22(2001), p.1563.

[6] Y. S. Lee, T. J. Kang and J. K. Lee : J. of the Korean Fiber Society, Vol. 28(1991), p.707.

[7] J. E. Oh, C. H. Lee, H. J. Sim, H. J. Lee, S. H. Kim and J. Y. Lee: Int. J. of Precision Engineering and Manufacturing, Vol. 8(2007), p.54.

[8] M. Sahin and H. J. Wilson: J. of Non-Newtonian Fluid Mechanics, Vol. 147(2007), p.79.

[9] Z. Z. Li, K. S. Heo and S. Y. Seol: International Journal of Precision Engineering and Manufacturing, Vol. 9(2008), p.51.

[10] R. J. Goldstein, E. M. Sparrow and D. C. Jones: Int. J. Heat and Mass Transfer, Vol. 16(1973), p.1025.

[11] J. R. Lloyd and W. R. Moran,: Journal of Heat Transfer, Vol. 96(1974, ) p.443.
