Sensitivity Analysis on Effect of Parent Materials Parameter on Formability of Tailor Welded Blank

Abstract:

The parent sheet selection in TWB designing is largely dependant on the effect of parent materials parameters on formability of TWBs. Experiments and FE simulations were performed to study the effect of material parameters of TWB’s parent sheets such as t (thickness ratio), k (strength factor of materials), n (strain hardening index), r (anisotropy index) on LDH and weld-line movement of TWB. Orthogonal experiments and range analysis were used to analyze the sensitivity on effect of different parameter on LDH and weld-line movement. The results show that LDH of TWB decreases with increasing ration of stronger sheets parameters to weaker ones, and the rate decreases gradually; in contrary, weld-line movement increases and the increasing rate decreases gradually. Furthermore, different parameters make various contributions to LDH and weld-line movement of TWBs and the effect degree of each parameter changes with different thickness ratios.

• Periodical: Applied Mechanics and Materials (Volumes 26-28)
• Pages: 1177-1183
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.26-28.1177
• Online since: June 2010
• Authors: Xin Yang Tao, Jian Ping Lin, Shui Sheng Chen
• Keywords: Limit Dome Height (LDH), Sensitivity Analysis, Tailor Welded Blank (TWB), Weld-Line Movement

References

[1] Panda, S.K. and D.R. Kumar: Improvement in formability of tailor welded blanks by application of counter pressure in biaxial stretch forming. 2008. 204(1-3): pp.70-79.

DOI: 10.1016/j.jmatprotec.2007.10.076

[2] Lee, W., et al., Experimental and numerical study on formability of friction stir welded TWB sheets based on hemispherical dome stretch tests. 2009. In Press, Corrected Proof.

DOI: 10.1016/j.ijplas.2008.08.005

[3] Cheng, C.H., L.C. Chan and C.L. Chow, Weldment properties evaluation and formability study of tailor-welded blanks of different thickness combinations and welding orientations. 2007. 42(15): pp.5982-5990.

DOI: 10.1007/s10853-006-1126-0

[4] Cheng, C.H., et al., True stress-strain analysis on weldment of heterogeneous tailor-welded blanks-a novel approach for forming simulation. 2007. 49(2): pp.217-229.

DOI: 10.1016/j.ijmecsci.2006.08.012

[5] Chan, L.C., et al., Formability and Weld Zone Analysis of Tailor-Welded Blanks for Various Thickness Ratios. Journal of Engineering Materials and Technology, 2005. 127(2): pp.179-185.

DOI: 10.1115/1.1857936

[6] P, K.S., Circular Grid Systems: A Valuable Aid for Evaluation Sheet Forming. Fuel and metallurgical Journals, 1969. 45: pp.633-640.

[7] Chen, W., G.S. Lin and S.J. Hu, A comparison study on the effectiveness of stepped binder and weld line clamping pins on formability improvement for tailor-welded blanks. 2008. 207(1-3): pp.204-210.

DOI: 10.1016/j.jmatprotec.2007.12.100

[8] Padmanabhan, R., M.C. Oliveira and L.F. Menezes. Deep drawing of aluminum-steel tailor welded blanks. 2008. 29(1): pp.154-160.

DOI: 10.1016/j.matdes.2006.11.007
