Vibration Analysis on Convey Paper Belt of Infeed Unit

Abstract:

The precondition of improve the printing press velocity is to maintain the minimum vibration of infeed unit within the range of press speed. Taking advantage of the equivalent relation between the formula of infinitesimal energy and the classic beam theory, the vibration of convey paper belt can be converted into the problem of the beam be stretched and be compressed, and then we utilize the finite element simulation technology to conduct model analysis for the convey paper belt. When the numerical of the belt speed gain ,both the vibration and shape distortion reach the maximum, as well as speed of the infeed unit will be influenced most.

• Periodical: Applied Mechanics and Materials (Volume 262)
• Pages: 377-381
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.262.377
• Online since: December 2012
• Authors: Wei Cheng Bao, Hong Chen, Yan Mei Liang
• Keywords: Finite Element, Infeed Unit, Printing Press

References

[1] H. Chen: Modern Printing Machinery Principle and Design(China Light Industry Press, China 2007).

[2] L.G. Pu and M.G. Ji: Design of Machinery(Higher Education Press, China 2006).

[3] Y.X. Li,S.S. Hao and X.T. Liu: Design of Machinery (2010)NO. 02,P. 13.

[4] Y.Y. Wang: Research on Dynamical Characteristic Model from Several Aspects for Belt Conveyor(MS, Northeastern University, China 2006).

[5] Jerry.K. Ginsberg: Mechanical and Struatural Vibrations(China Astronautic Publishing House, China 2005).

[6] J.J. Leng,J. Zhao and Y. Zhang: Finite Element Technological Base(Chemical Industry Press, China 2007).

[7] D.B. Li: Experiment Modal Analysis and Application(Science Press, China 2001).
