The Finite Element Study of the Compressive Strength of Typical Waveform Corrugated Box

Abstract:

The finite element model of a 0201 V-shaped, U-shaped, and UV-shaped single corrugated board corrugated boxes are established. The stress distribution and strain of the three types of waveform corrugated box to withstand the pressure of the top surface stacking are calculated. Three kinds of corrugated board compression are analyzed. Analysis of the structure shows that the V-shaped corrugated board has good rigidity, U-type corrugated box has good cushioning properties, and the range during which the UV type is a better choice. This is consistent with the experimental results, prove the validity of the finite element analysis, and provide data basis for optimization design of the shape of the corrugated board corrugated waveform.

• Periodical: Applied Mechanics and Materials (Volume 262)
• Pages: 390-394
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.262.390
• Online since: December 2012
• Authors: Wei Yuan, Wen Cai Xu, Gai Mei Zhang, Li Hua Xie
• Keywords: Compressive Strength, Corrugated Box, Corrugated Waveform, Finite Element Analysis (FEA)

References

[1] Peng Guoxun. : Logistic and Transport Packaging Design (Printing Industry Press, 2006.)

[2] Zhang Shubin, Feng Xuezheng: Experiment Research of Corrugated Boxes Compression Strength. Packaging Engineering, 2008, 29(9)：10-11.

[3] Nordstrand T:Analysis and testing of corrugated board panels into the postbuckling regime Compos Struct 2004(63):189--99.

[4] TalbiN, BattiA, AyadR GuoYQ: Compos Struct, 2008(4):8-19.

[5] Jongkoo Han, Jong Min Park: Packaging Technology and Sconce, 2007, 20:39-47.

[6] Isaksson P, Krusper A, Gradin P A:Composite Structures, 2007(80):123-130.

DOI: 10.1016/j.compstruct.2006.04.066

[7] Aboura Z, Talbi N, Allaoui S, Benzeggagh M L: Elastic behavior of corrugated cardboard: experiments and modeling. Compos Struct, 2004(63):53-62.

DOI: 10.1016/s0263-8223(03)00131-4

[8] Saeed Moaveni: Finite Element Analysis Theory and Application with ANSYS(Publishing House of ElectronicsIn dustry, 2003)

[9] Urbanik T J, SalikiisEp : Wood Fiber Sci, 2003(35): 322-333.

[10] Nordstrand T M: Compos Struct, 2004(65):1-6.

[11] Bianeolini M E, Brutti C: Pack Technol Sci, 2003(16):47-60.

[12] Cheng Q H, Lee H P, Lu C:Composite Structures, 2006(74):226-236.
