An Asynchronous Motor Soft-Starter with Discrete Variable Frequency Technology

Abstract:

This paper analysis the control principle of the asynchronous motor soft-start with discrete variable frequency technology．A simulation model for the asynchronous motor soft-starter using discrete variable frequency technology is built based on MATLAB SIMULINK/POWER SYSTEM．In start process, positive sequence sub - frequency such as 13、10、7、4 discrete variable frequency is used in the soft-starter to simplified power circuit and its control. While on the power frequency time slice ,a single neuron PID algorithm is used to limit the current. The simulation results verify the asynchronous motor soft-starter with discrete variable frequency technology not only reduces the initial firing current but also has bigger start torque, which has a faster start speed compared with the normal soft starter with current limit starting control technology.

• Periodical: Applied Mechanics and Materials (Volumes 263-266)
• Pages: 686-690
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.263-266.686
• Online since: December 2012
• Authors: Yao Yan, Hong Hua Wang
• Keywords: Asynchronous Motor, Discrete Variable Frequency, Positive Sequence, Soft-Start

References

[1] A.Ginart, J.S. Camilleri and G.Pesse,thyristor controlled AC induction motors using a discrete frequency control method, 29th Southeastern Symposium on System Theory,1997: 164~167

DOI: 10.1109/ssst.1997.581599

[2] Honghua Wang, Development of Soft Starting Technologies for Asynchronous Motor[J].Machinery manufacturing and automation,2011(3)：1-5.( In Chinese)

[3] Chao Yan,Simulation and Research of Discrete Frequency Surge Soft Start Control for Induction Motor[D].Beijing:North China Electric Power University，2008.( In Chinese)

[4] Xiaohong Tang ，Honghua Wang ,Simulation of Asynchronous Motor Soft-starter Based on Single Neuron PID[J].Machinery manufacturing and automation,2011,5. (In Chinese)

[5] Zhiting She ,Miyang Zhou ,Yu Pi and so on:Research on High Torque Soft Starter of AC Motors Based on Discrete Frequency[J]. Power Electronic Technique,2010,44(2):58-59.(In Chinese)

[6] Donghui Li ,Yuexian Ma , Bo Wang .Novel Speed Measuring Method of Discrete Variable Soft Starting and Its Application [J]. Electric Drive , 2007, 37(11) : 14-17.(In Chinese)

[7] Shizhang Xu.Electromechanics[M].Beijing:Machine Industry Publishing House,1996.(In Chinese)

[8] Boshi Chen. Electricity pull automation control system [M].Beijing:Machine Industry Publishing House，2000.(In Chinese)

[9] Li Liu ,Dong Wang ,The practical techniques of asynchronous motor soft starter[M].BeiJing:China Electric Power Publishing Company,2009.(In Chinese)

[10] Dongyan Zhang ,Yaqiu Liu ,Jun Cao;Application of single neuron adaptive PID controller during the process of timber drying[C].Journal of Forestry Research, 14(3): 244-248 (2003).(In Chinese)

DOI: 10.1007/bf02856839
