A Multi-Level-Objective-Oriented Method for Coordination and Control of Voltage and Reactive Power in Distribution Network

Abstract:

A multi-level-objective-oriented method for coordination and control of voltage/reactive power in distribution network is proposed. By referring to the demand for integrated voltage and reactive power control between county and district power network, three-level objective include regional voltage control of the gate area, gate power factor control and reactive control within the power station of the gate area. The control strategy of the adjusting unit based on the nine-zone theory is analyzed, and then the correspondence between the global AVQC and local VQC is discovered, based on which the optimal and suboptimal control strategy of the adjusting unit are proposed. Finally, three steps including urgently cutting off the capacitors, combinatorial control of the capacitors and combinational control of the transformer stalls are taken one after another to realize the coordination and control over the voltage and reactive power between the superior and inferior power network. This method is implemented in the AVQC system of TianJin Chengxi grid, which operates stably and has gained good effect.

• Periodical: Applied Mechanics and Materials (Volumes 263-266)
• Pages: 664-669
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.263-266.664
• Online since: December 2012
• Authors: Lin Xie, Yi Rong Su
• Keywords: Coordination and Control, Distribution Network, Global Voltage and Reactive Power Control, Multi-Level-Objective

References

[1] Su Yirong, Hong Cheng, Liang Huifang, etc. Improved AVQC Method of the Nine-zone Graph Theory Based on Identification of the Adjusting Unit. Automation of Electric Power System,vol.30(2),2006, pp.77-80.

DOI: 10.1049/cp:20061646

[2] Tong Qingyi, Yan Gangfeng. Voltage and Reactive Power Control Based on Real-time Database. Relay, vol.29(10), 2001, pp.22-25.

[3] Shi Yuxiang, Tao Xiaonong. Automatic Voltage Controller and Its Application to Substation. Automation of Electric Power System,vol.29(10), 1996, pp.54-57.

[4] Huo Jingqiang.DWK-Ⅲ Type Comprehensive Voltage and Reactive Power Control Device. Automation of Electric Power System,vol.23(9),1999, pp.50-53.

[5] Zhao Dengfu, Si Zhe, Yang Jing, etc. Research of a New Integrated Control Set for Voltage and Reactive Power in Substation. Power System Technology, vol.24(6), 2000,pp.14-17.

[6] Ding Xiaoqun, Chen Sheng, Xu Xingtao,etc. Application of Optimization and Centralized Control System for Reactive Power/Voltage in TaiZhou Power Network. Relay, vol.24(12),2000,pp.21-24,44.

[7] Huang Hua, Gao Zonghe, Dai Zemei, etc. Design and Application of AVC System for District Power Network Based on Control Modes. Automation of Electric Power Systems,vol.29(15),2005,pp.77-80.

[8] Niu Huanna, Yang Minghao, Geng Guangfei, etc. Research and development of voltage-reactive power global optimization distributed control system. Relay, vol.34(9),2006,pp.21-25.
