Regulator Strategies for Switched Reluctance Generators Based on Direct Energy Control

Abstract:

The causes of voltage ripples in switched reluctance generator (SRG) are analyzed. At first, on the foundation of the driving circuit with a three-level topology, the energy conversion relations in different rotator positions or in different electric level states was set up. Secondly, the SRG outputting voltage was controlled by a new method named direct energy control. Then, the hysteresis control logic of the direct energy control was designed. At last, we conduct the simulation experiments. The simulation results show that this method can effectively decrease the output voltage ripples of SRG.

• Periodical: Applied Mechanics and Materials (Volumes 263-266)
• Pages: 718-722
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.263-266.718
• Online since: December 2012
• Authors: Yong Zhi Liu, Zeng Jin Sheng
• Keywords: Direct Energy Control, Switched Reluctance Generator, Three-Level Topology, Voltage Ripple

References

[1] MacMinn S R, Sember J W. Control of a switched-reluctance aircraft starter-generator over a very wide speed range, in Proc[J]. Intersociety Energy Conversion Engineering Conf, 1989:631-638.

DOI: 10.1109/iecec.1989.74532

[2] Radun A. Generating with the switched-reluctance generator in Proc[J]. IEEE APEC'94, 1994: 41-47.

[3] Martin Liptak Valeria Hrabovcova． Equivalent Circuit of Switched　Reluctance Generator Based on Series Generator, Journal of　Electrical Engineering VOL 59.NO.12008 23-28.

[4] Panda D，Ramanarayanan V．Mutual coupling and its effect on steady-state performance and position estimation of even and odd number phase switched reluctance generator drive［J］．IEEE Transactions on Magnetics，2008，43(8):3445－3456.

DOI: 10.1109/tmag.2007.898101

[5] Manolas I S，Kladas A G，Manias S N．Finite element based estimator for high performance switched reluctance machine drives［J］．IEEE Transactions on Magnetics，2009，45(3):1266－1269.

DOI: 10.1109/tmag.2009.2012590

[6] Wen Ding,Deliang Liang.Comparison of transient and steady state performances analysis for a dual channel switched reluctance machine operation under different modes［J］．IET Electric Power Applications，2010，4(8):603－617 .

DOI: 10.1049/iet-epa.2009.0282

[7] Wen Ding,Deliang Liang.Modeling and simulation of dual-channel switched reluctance starter/generator system[J].Electronic Machines and Control，2011，15(5):7－15.

DOI: 10.1109/icems.2005.202592

[8] Hanmei Peng,LingzhiYi,Jianlin Zhu.Study and simulation for switched reluctance generator output voltage ripple reduction[J].Journal of System Simulation,2010,22(5):1237-1241.
