RFID-Driven Graphical Method for Describing the Time-Sensitive State and Position Changes of WIP Material Flows in a Job-Shop Floor

Abstract:

The purpose of this work is to develop a graphical method for describing the work-in- progress (WIP) material flow of a workpiece in order to realize RFID-driven real-time data sampling and support following-up Auto-ID computing. Firstly, various processes in a job-shop floor are formalized graphically by using different types of state-blocks, which depend on RFID detecting spaces and tag detections. And then an event set is deduced from the connecting relations among state blocks and is used for creating the event-driven graphical model in the context of the WIP material flow of a workpiece. To verify the feasibility of the proposed method, a description case is given.

• Periodical: Applied Mechanics and Materials (Volume 273)
• Pages: 97-102
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.273.97
• Online since: January 2013
• Authors: Wei Cao, Ping Yu Jiang, Juergen Sauser, Jochen Deuse
• Keywords: Graphical Schema, Job-Shop Floor, Material Flow, Position Changes, Radio Frequency Identification (RFID), State

References

[1] G.Q. Huang, et al.: International Journal of Adv Manuf Technol 36 (2007) pp.752-76.

[2] Günther, et al.: RFID in Manufacturing, Springer, Germany. (2008).

[3] P.Y. Jiang, et al.: accepted by Proccedings of iMechE Part B Journal of Engineering Manufacture raphical esses in cesses in flown depth er researches, auto-ID computing methods will be coupled with the method proposed in this paper. (2011).
