Research on Hydrostatic Supporting Temperature-Rise of Heavy NC Machine Tool

Abstract:

With heavy NC machine tool is widely used in many oil pad round guide hydrostatic bearing as the research object, in the under condition of variable viscosity, establish oil film viscosity-temperature equation. Adopt finite volume method, simulation the hydrostatic bearing internal fluid temperature field under different flow rates on the speed of 6R / min. Numerical simulation hydrostatic thrust bearing oil film temperature field, can find a general high temperature region, and then take effective control temperature. It can achieve the hydrostatic thrust bearing oil film temperature field prediction for engineering practical oil chamber structure, offer the theoretical foundation for optimization design.

• Periodical: Applied Mechanics and Materials (Volume 274)
• Pages: 132-135
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.274.132
• Online since: January 2013
• Authors: Yan Qin Zhang, Rui Li, Chun Xi Dai, Jun Peng Shao, Xiao Dong Yang, Gui Tao Sun
• Keywords: Heavy Vertical Lathe, Hydrostatic Guide, NC Machine Tool, Temperature Field

References

[1] Heinrichson Niels，Santos Ilmar Ferreira. The influence of injection pockets on the performance of tilting-pad thrust bearings. Journal of Tribology，Vol. 129 (2007), pp.895-903.

DOI: 10.1115/1.2768609

[2] Z. Yan-qin, Y. Xiao-dong. Viscosity Influence Research on Load Capacity of Heavy Hydrostatic Bearing. Key Engineering Materials, Vol. 450(2010), pp.63-66.

DOI: 10.4028/www.scientific.net/kem.450.63

[3] Z. Yan-qin, Y. Xiao-dong. Research on Influence of Cavity Depth on Load Capacity of Heavy Hydrostatic Bearing in Variable Viscosity Condition. Advanced Materials Research, Vol. 129(2010), pp.1181-1185.

DOI: 10.4028/www.scientific.net/amr.129-131.1181

[4] Z. Yan-qin, S Jun-peng, N Shi-qian. Numerical simulation of temperature field in large size hydrostatic bearing. China Mechanical Engineering, Vol. (2008), 19: pp.563-565.

[5] S. Jun-peng, Z. Yan-qin. Influence of load capacity on hydraulic journal support deformation in finite element calculation. Journal of Central South University of Technology, Vol. 15 (2008), pp.245-249.

[6] S. Junpeng, Z. Yanqin, L. Pengcheng. Static Flow Simulation of Hydrostatic Bearing Ellipse and Sector Curve Based on Fluent. Lubrication Engineering, Vol. 32(2007), pp.93-95.

[7] S. Junpeng, Z. Yanqin: Journal of Hydrodynamics(Ser. A), Vol. 24(2009), pp.119-123.

[8] Y. Xiao-dong, Research on Lubrication Performance of Super Heavy Constant Flow Hydrostatic Thrust Bearing. Advanced Science Letters, Vol. 4(2011), pp.2738-2743.

[9] Y. Xiao-dong, Research on Temperature Field of Hydrostatic Thrust Bearing with Annular Cavity Multi-pad. Applied Mechanics and Materials Vol. 121 (2012), pp.3477-3480.
