Seismic Response Analysis of a Large Span Bridge with Inconsistent Inputs

Abstract:

Seismic response of a large span cable based bridge with inconsistent inputs is analyzed in this paper. The bridge model is built by the function of finite element software ANSYS. The free vibration characteristics of the bridge are analyzed by Lanczos Vector Iterative method. The first and the twentieth free vibration frequencies are 0.06808 Hz and 0.54392 Hz respectively. A set of motions of consistent, traveling wave and synthesized (inconsistent) are adopted as inputs at the two supports. The lengthwise, lateral and vertical displacements at the span center and quarter span of the main girder, at the tops of the supporting towers, and the internal forces in the girder and at the base of the towers are calculated. The result shows obviously the necessity to take into account inconsistent input in seismic response analysis of large span bridge.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 1389-1392
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.1389
• Online since: January 2013
• Authors: Liang Wang, Xia Xin Tao, Hai Ming Liu, Wen Jun Gao
• Keywords: Inconsistent Input, Large-Span Bridge, Seismic Response Analysis

References

[1] M. Berrah, E. Kausel: EESD, Vol. 21(1992), p.461.

[2] A. Der Kiureghian, A. Neuenhofer: EESD, Vol. 21 (1992), p.713.

[3] Wang Junjie, Wang Qianxin: Vibration Engineering (in Chinese), Vol. 8(1995), p.119.

[4] C. H. Loh: EESD, Vol. 13(1985), p.561.

[5] R. Harichandran, E. Vanmarke: ASCE (EM), Vol. 112(1986), p.154.

[6] Qu Tiejun, Wang Junjie, Wang Qianxin: ACTA Seismologica Sinica, Vol. 18(1996), p.55.

[7] TAO Xiaxin, WANG Guoxin: ACTA Seismologica Sinica, Vol. 16(2003), p.205.

[8] TAO Xiaxin and WANG Haiyun, in: 13WCEE (Vancouver, 2004). Paper No. (1945).

[9] Wang H. Y. and X. X. Tao: Journal of Harbin Institute of Technology, Vol. 37(2005), p.1533.

[10] Zhang D. L., X. X. Tao, Z. H. Zhou: Northwestern Seismological Journal (in Chinese), Vol. 27(2005), p.193.

[11] Wang Liang, Dissertation for Master Degree (in Chinese), Harbin Institute of Technology, China (2012).

[12] Tu Zhengfei, Manual of application cases of finite element analysis by ANSYS. China Construction Industrial Press (in Chinese, 2010).

[13] Xia Jianfang, Ye Hainan. Finite element method principle and the application of ANSYS. National Defense Industrial Press (in Chinese, 2011).
