The Fundamental Characteristics on Particle Size Distribution of Drilling Rock-Cuttings

Abstract:

The properties of particle size distribution of rock cuttings and its shape characteristics are the most important parameters to petroleum drilling engineering. The samples of rock drill-cuttings are collected from 7 wells within the depths of 3500 m in Liaohe Oilfield of China. The particle size distribution laws of these rock samples with the average diameter over 74 μm are analyzed. The result shows that the drill cuttings feature obvious sheet shape and the size distribution curve of the particles is mainly related to the formation rocks and drilling bits. While drilling at the well depths of between 0 and 2000m by the cone bits, particle size distribution of drill cuttings has a form of approximately power function, the probability particle diameter being 8.50～9.27 mm. Drilling at the depths of between 2000 and 2800 m by the cone bits, the size distribution of cuttings has a form of nearly function, the probability particle diameter being 3.04～4.67 mm. Drilling at the depths under 2800m by PDC bits, the size distribution has a form of nearly the Rayleigh distribution, the probability rock diameter being 0.91～0.94 mm.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 2411-2414
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.2411
• Online since: January 2013
• Authors: Song Lin Yi, Zhi Ming Wang, Xian Zhong Yi, Wei Chang
• Keywords: Drill Cuttings, Inherent Properties, Particle Size Distribution, Probability Diameter, Sheet Particle

References

[1] Sanjiang Jin, Xuejun Wang, Quan Chen etal, Solid control technology in well HALDA-1: A brief introduction on solid control abroad, Drilling Fluid and Completion Fluid, 1999, 16(4): 39~41. IN Chinese.

[2] Zaisi Zhu, Yihua Kang, Xuehui Li, The present situation and trend of development of the drilling fluid purification system, China Petroleum Machinery, 2001, 29 (supplement): 111~113. IN Chinese.

[3] Langbo Cao, Zhilan Peng, Chengzhi Fan etal, NCS250 Cyclone cleaners utilizied in Zhongyuan Oilfield. China Petroleum Machinery. 2003, 31 (9): 62~63. IN Chinese.

[4] Moore P L, Drilling practices Manual, Tulsa: Petroleum Publishing Co. 1974: 1~150.

[5] Li Li, Hongbin Liu, Xiangping Yang etal, Study on sedimentation law of cuttings grains in solid/liquid separator, Natural Gas Industry , 2005, 25 (11): 62~65. IN Chinese.

[6] Weibing Zhu, Jingjiang Yan, Kinetical law of solids particles on a shale shaker, Chinese Journal of Mechanical Engineering. 2005, 41 (10): 231~234. IN Chinese.

DOI: 10.3901/jme.2005.10.231

[7] Weibing Zhu, Computer simulation and experiment for the conveyance motion of solid phased particle on sieve surface of well drilling shaker. Journal of Machine Design, 2005, 22 (1): 50~52. IN Chinese.

[8] Hongbin Liu, Minghong Zhang, Analysis on moving rule of solids inside dynamic machine for drilling fluid, Western China Exploration Engineering, 2006, 18 (10): 207~20. IN Chinese.

[9] Johnson PW, Design techniques in air and gas drilling cleaning criteria and minimum flowing pressure gradients, Paper SPE 23550, Society of Petroleum Engineers of AIME, October, (1991).

DOI: 10.2118/95-05-02

[10] Xianzhong Yi, Study on basic physical properties and settling behavior of flake drilling rock cuttings, Research reports of Tsinghua University postdoctoral fellows, Beijing, 2006. IN Chinese.
