Analysis on Dynamic Piezoelectric Coupling Characteristics of PZT-4

Abstract:

Structural behavior of piezoelectric stacks has a great impact on electromechanical conversion efficiency of highway piezoelectric generators. In this paper, a single piezoelectric ceramic chip in piezoelectric stack structure was regarded as the object of study to construct the ANSYS model of a single piezoelectric ceramic entity. The selection of SOLID5 makes the piezoelectric ceramic chip into the grid cube and by the coupling field, maintains five aspects of static and dynamic piezoelectric coupling characteristic simulation analysis respectively, including static analysis, modal analysis, harmonic analysis, transient analysis and circuit simulation analysis. The results of all the analyses for the optimal structure design of highway piezoelectric generators are to provide a reference.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 2432-2435
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.2432
• Online since: January 2013
• Authors: Yan Zhao, Yu Feng Li, Song Wei Wang, Yin Huan Zheng
• Keywords: Finite Element, Piezoelectric Coupling, PZT-4

References

[1] Junwu Kan, Kehong Tang, Shuyun Wang, Zhigang Yang,  JIA Jie, Ping Zeng. Modeling and simulation of piezoelectric cantilever generators [J]. OPTICS AND PRECISION ENGINEERING, 2008, 16(1): 71-75.

[2] R. Amirtharajah and A.P. Chandrakasan, Self-Powered signal processing using vibration- based power generation, IEEE JSSC, 33(5): 687-695.

DOI: 10.1109/4.668982

[3] Xi Zang. Analysis of infinite element about electromechanical conversion performance of piezoelectric generator. Thesis of Wuhan University of Technology [D], 2012. 5.

[4] H.A. Sodano, G. Park, D.J. Leo et al., Use of piezoelectric energy harvesting devices for charging batteries, Proc. of SPIE, 2003, 5050: 101-8.
