Grey Dynamic Filtering in the Non-Diffracting Beam Triangulation Measurement

Abstract:

To solve the problem of speckle noise, CCD photoelectric noise and background light noise in non-diffracting beam triangulation and improve measurement accuracy and resolution, we use gray dynamic filtering theory. In the non-diffraction beam triangulation measurement system, the measured signal is reconstructed at the maximum peak of the spots by implementing the dynamic GM genetic filtering methods based on the grey system theory. There are only four main steps of modeling. The first step is to update the system dynamically and continuously. The second step is to effectively obtain low frequency trend component,The third step is solving the problem of the low rate of complex multi-measurement.The last is solve the problem of the limit of unsuitable online measurement. This method of triangulation measurement based on the non-diffracting beam have higher measurement accuracy and higher resolution over the traditional laser triangulation measurement system.

• Periodical: Applied Mechanics and Materials (Volumes 278-280)
• Pages: 753-756
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.278-280.753
• Online since: January 2013
• Authors: Jian Ning Yang, Qian Qian Wang, Zhou Qing
• Keywords: Grey Dynamic Filtering, Noise, Non-Diffracting Beam, Triangulation Measurement

References

[1] Wang Xiaojia. Survey on the Laser Triangulation. Chinese Journal of Scientific Instrument. (in Chinese) Vol. 601-608 (2004), p.54.

[2] J. Durnin. Exact solutions for non-diffracting beams 1: the scalar theory. J. Opt. Soc. Am. 1987 (A4): 651-654.

[3] H. Rothe. Improved accuracy in laser triangulation, Opt. Eng. 1992. 31(7): 1538-1545.

[4] Chen Qinghu. Wavelet analyzing Method for Removing Noise in Triangulation Measuring System with Non-diffracting Beam. Tool Engineering. 1999. 3(7): 32-35.

[5] J. Deng. The primary methods of grey system theory. Huazhong University Press, (2004).
