Virtual Model of Tool Path for Milling Machine at Classical Design Base

Abstract:

This article focuses on issue of proposal ideal tool paths for machine tools. Model of machine consists from 6 basic knots where milling machine disposes spindle placed in the horizontal direction are. Based on mathematical analysis we can detect the movement of machine axes for uncertainty investigated. The calculated values can be compared with machine model developed in Computer - Aided Design. Defining the shape of workpiece as well as assigning an appropriate instrument can be determined by true value of precision workpiece. After substituting the values of specific dimensions we get the final position of vectors point for contact in tool coordinate systems at individual model solids.

• Periodical: Applied Mechanics and Materials (Volume 282)
• Pages: 235-241
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.282.235
• Online since: January 2013
• Authors: Ján Semjon, Peter Demeč, Jozef Svetlík
• Keywords: Accuracy, Machine, Tool, Virtual Model

References

[1] M. Cillikova, J. Salaj, A. Micietova, Influence of Cutting Fluids on Cutting Forces When Grinding Bearing Steel. In Journal of Machine Manufacturing. (2009).

[2] P. Demec, M. Varchola, J. Svetlik, Using of mechatronics systems in designing of manufacturing machines. In Metalurgija/Metalurgy, (2010), vol. 49, No. 2, pp.604-608.

[3] P. Demec, J. Svetlik, J. Semjon, Virtuálne prototypovanie obrábacích strojov z hľadiska dynamiky procesov obrábania, Košice (2011), ISBN: 978-80-553-0815-9.

[4] P. Demeč, J. Svetlík, Virtual machining and its experimental verification, In: Acta Mechanica Slovaca, (2010), vol. 13, No. 4, pp.68-73.

DOI: 10.2478/v10147-010-0039-8

[5] Information on http: /www. secotools. com/sk.
