Design of Precise Lightweight Mirror

Abstract:

The presented paper shows results from the mechanical design of lightweight mirrors for space applications, where demand for maximum weight loss goes together with demands for sufficient strength, shape accuracy, and surface quality of optical surfaces. The paper illustrates the material properties of different materials, which are often used for manufacturing precise optics. It compares three materials – e.g. optical glass such as NFS-15, optical ceramic such as Zerodur, and Silicon-infiltrated sintered Silicon Carbide – from the point of view of suitability for machining and their mechanical and thermal properties. It also shows the possibility of mass reduction by using different geometries of lightweight structure. Paper shows the results of numerical simulations of specified load-cases and comparison of different lightweight structures and different materials with respect to their strength and stiffness.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 2717-2722
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.2717
• Online since: January 2013
• Authors: Tomáš Vít, Radek Melich, Jan Václavík, Vít Lédl
• Keywords: Lightweight Mirrors, Precise Optics, SiSiC

References

[1] Shott, Optical Glass Data Sheets. www.schott.com (2009)

[2] Crystran Ltd., www.crystran.co.uk/materials-data.htm (2009)

[3] Corning, www.corning.com (2006)

[4] Hoya Corporation, Optical Glass Master Datasheet, Excel file, www.hoyaoptics.com/products/document_library.htm (2010)

[5] P.R. Yoder, Opto-mechanical Systems Design, Bellingham, Wash., SPIE, Pg 119-120. (2006)

[6] Information on Matweb, Material Property Data. 201, www.matweb.com (2010)

[7] Information on ESA Science and Technology, Solar Orbiter, http://sci.esa.int/solarorbiter
