Design and Implementation of Engine Waveform Tester Based on Virtual Instrument

Abstract:

Engine fault diagnosis and detection is inseparable from the analysis and examination of each sensor or actuator, and the waveform display is the most intuitive and convenient way. This system is an engine waveform tester developed based on virtual instrument and the batch estimate fusion theory is used in the process of the single sensor data acquisition and processing. It is proved by practice that this instrument can conveniently and quickly realize the functions such as signal acquisition and control, waveform analysis and processing and result expressing and output, thus providing technical support for comprehensive intelligent engine fault diagnosis technology.

• Periodical: Applied Mechanics and Materials (Volume 288)
• Pages: 223-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.288.223
• Online since: February 2013
• Authors: Jin Gang Ma, Hong Ying Song, Jiang Li Hou
• Keywords: Batch Estimate Fusion, Virtual Instrument (VI), Waveform Testing

References

[1] Chunlong Ma and Qiying Zhang: Wireless network positioning algorithm based on Gauss function and batch estimation fusion. Journal of Changchun University of Technology(Natural Science Edition), (2012) No. 2.

[2] Xiliang Zhang and You Sun: A data aggregation arithmetic based on directed diffusion and batch estimate for wireless sensor network. Microcomputer Information, (2006) No. 25.

[3] Zengfang Li. Research on the Fault Diagnosis Expert System of Engines Based on Artificial Intelligence and Virtual Instrument Technology (Ph.D., Zhejiang University, China 2004).

[4] Shiping Zhu: Sensors and Testing Technology (Beijing University Press, China 2006).
