The Simulation Analysis of the Efficiency about Truck Crane Lifting Load Sensing Hydraulic Loop

Abstract:

In this paper, the energy consumption of the truck crane lifting load sensing (LS) hydraulic loop is analyzed. AMESim is applied to model it, based on the design of a 70t truck crane lifting loop. And then the efficiency of it is simulated, comparing with the traditional truck crane lifting hydraulic loop. The simulation results clarify that the efficiency of the LS lifting hydraulic loop is obviously improved compared with the efficiency of the traditional one. Its efficiency has nothing to do with the load speed and is only related with the load. The results are useful to the design of large-tonnage truck crane lifting hydraulic loop.

• Periodical: Applied Mechanics and Materials (Volume 288)
• Pages: 233-237
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.288.233
• Online since: February 2013
• Authors: Ye Fei, Bin Bian, Yuan Yuan Li
• Keywords: AMEsim, Efficiency, Load Sensing, Simulation, Truck Crane

References

[1] Yan Wang, Junke Hu, Bo Yang. The Simulation and The Dynamic Characteristics Analysis of the Load-sensing Pump. (Modern Manufacturing Engineering, China 2008). (In Chinese).

[2] Aiwu Zhang. The Hydraulic System Design of Large-tonnage Truck Crane. (Construction Machinery, China 2007). (In Chinese).

[3] Yi Jin, Bo Fu, Xuan Fu. The Operating Characteristics Analysis of Multiple Valve Load Sensing System. (Hydraulic Pneumatic and Sealing, China 2011). (In Chinese).

[4] Ye Fei, Tao Chen, Xueshou Jiang. Hydraulic System Design of Large-tonnage Horizontal Direction Drilling Machine. (Hydraulic and Pneumatic, China 2011). (In Chinese).

[5] Wanli Li. The Design of Hydraulic System. (Tongji University Press, China 2011).
