Research on Coupled Water Hammer in Hydraulic Pipe System

Abstract:

A one-dimensional mathematic model is presented which describes pressure fluctuations behavior of liquid-filled pipes. The model is based on conventional two-equations water hammer theory. Here is multi-water-hammer occurring simultaneously and coupling together. The differences are obvious when taking into account coupled water hammer and just single water hammer in Fluid pipe system by comparing the numerical simulation. The pressure characteristics located where water hammer takes place is investigated by numerical simulation and experiment. Then the factors of influencing on the coupled water-hammer pressure and frequency are considered, the result shows that system parameters effecting on it are critical and should be detailedly analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 29-32)
• Pages: 401-406
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.29-32.401
• Online since: August 2010
• Authors: Jin Jun Liao, Bao Ren Li
• Keywords: Coupled Water Hammer, Fluid Pipe, Fluid Transients, MOC

References

[1] M.C.P. Brunelli: Two-dimensional pipe model for laminar flow. J fluids engineering, Vol. 127(2005), pp.431-437.

DOI: 10.1115/1.1905645

[2] A.S. Tijsseling: Water hammer with fluid-structure interaction in thick-walled pipes. J computer & structure, Vol. 85(2007), pp.844-851.

DOI: 10.1016/j.compstruc.2007.01.008

[3] Arris S. Tijsseling and Alexander Anderson: Johannes won Kries and the history of water hammer, J hydraulic engineering, pp.1-8.

[4] Fluid power control, edited by J. S. Blackburn and G. Reethof, sWiley, New York(1960), p.85.

[5] Joukowsky N: On the hydraulic hammer in water supply pipes, English translation by OSimin: Water hammer 1898, Proceedings of the American Water Works Association(1904), Vol. 24, pp.341-424.

[6] L. Allevi.: Theorie general du movement varie de l'eau dans less tuyaux de conduit. Revue de Mecanique, Paris, France, Vol. 14(Jan-Mar) (1904); pp.10-22 and pp.230-259.

[7] C. S Watt., J.M. Hobbs and A. P Boldy: Hydaulic Transients Following Valve Closure. Journal Hy. Div. ASCE, Vol. 106(1980), pp.1627-1640.

DOI: 10.1061/jyceaj.0005533

[8] Wylie EB, Streeter VL: Fluid transients. New York: McGraw-Hill 1978. (Republished with minor corrections by FEB Press, Ann Arbor, Michigan, USA. 1983. ).

[9] Wylie EB, Streeter VL: Fluid transients in systems. Englewood Cliffs, New Jersey, USA: Prentice Hall (1993).

[10] Wiggert, D.C., Tijsseling, A.S.: Fluid transients and fluid-structure interaction in flexible liquid-filled piping. ASME Applied Mechanics Reviews, Vol. 54(2001), pp.455-481.

DOI: 10.1115/1.1404122

[11] Zhang, L., Tijsseling, A.S., Vardy, A.E.: FSI analysis of liquid-filled pipes. Journal of Sound and Vibration, Vol. 224 (1999), pp.69-99.

DOI: 10.1006/jsvi.1999.2158
