Frequency Band Energy Statistics Method and the Applications in Monitoring the Work Conditions for Mechanical Equipments

Abstract:

A new manner, named frequency band energy statistics method, has been proposed for the analysis of the spectra from the vibration signals. The recorded vibration signals were first divided into multi-segments. Then each segment was calculated via the FFT transformation and 1/3 octave spectrum to obtained the characteristics of energy distribution, by making the histogram maps of the obtained features of the frequency energies. Consequently, we can monitor the work conditions and fault diagnosis for the mechanical equipments by the compared analysis of the corresponding histogram maps of equipments with normal and abnormal work conditions. The results show that present method exhibits a very strong sensitivity to the changes of vibration signal, leading to the fine detection of the minor changes form the equipment work conditions. Current work might provide a novel and facile method for definitely monitoring the work conditions and fault diagnosis of the mechanical equipments.

• Periodical: Applied Mechanics and Materials (Volumes 29-32)
• Pages: 78-83
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.29-32.78
• Online since: August 2010
• Authors: Yun Long Yuan, Chao Yong Yuan, Chao Zhen Yang
• Keywords: Energy Offset, Fault Diagnosis, Mechanical Vibration, Spectrum Analysis

References

[1] Sun Zhihui, Liu Xiaojuan. The Spectrum Analysis of Impulsive Signal [J]. Metallurgical equipment, 2006, (1) : 40-42.

[2] EO Brigham. Fast Fourier Transform [M]. Shanghai: Science and Technology Press, (1979).

[3] Tao Ran, Zhang Huiyun, Wang Yue. Multirate Digital Signal Processing Theory and its Application [M]. Beijing: Tsinghua University Press, (2007).

[4] Wang Ji, Hu Xiao. Matlab in Vibration Signal Processing [M]. Beijing: China Water Conservancy and Hydropower Press, (2006).

[5] Liu Yang, Sun Chao. New Method Used to Improving the Spectrum Resolution of Wide Band Signal[J]. Journal of Scientific Instrument, 2006, 27(6): 1141-1145.

[6] Lu Chen, Wang Guizeng. Noise Fault Diagnosis Based on Time-frequency Domain Model [J]. Vibration and Shock, 2005, 24 (2) : 54-57.

[7] Xia Yong, Shang Binliang, Zhang Zhenren. Application of Fractal Geometry to Analysis of Vibration Signal of I.C. Engines [J]. Vibration and shock, 2001, 20 (1): 59-61.

[8] Liu Xiaofeng, Bai Lin, Qin Shuren. Transient Impulse Signal Extraction Based on Selfadaptive Time-frequency Decomposition [J]. Journal of Mechanical Engineering, 2008, 44 (11) : 166-170.

DOI: 10.3901/jme.2008.11.166

[9] Xu Yongqiang, Shao Renping. Vibration Signal Analysis and Fault Diagnosis of Gears [J]. Mechanical Science and Technology, 2009, 28 (9) : 1216-1210.

[10] Yan Tingfei, Fang Guiqian. Research on 1/3 octave acoustic test control technique [J]. Spacecraft environmental engineering, 2008, 25 (5) : 463-466.
