Experimental and Numerical Study on Unreliability of Young’s Modulus Measurement by Conventional Split Hopkinson Bar

Abstract:

The split Hopkinson bar (SHB) technique has been widely used to determine dynamic plastic/damage properties of materials at high strain rates. But presently, a number of researchers used it to measure the so-called dynamic Young’s moduli. This paper aims at the feasibility to determine Young’s moduli by conventional SHB. The strain-stress curves of two kinds of metals, 45# steel and LY-12 aluminum, were measured by a conventional SHB facility. The corresponding numerical experiments were performed by ABAQUS/Explicit. The curves obtained by the both procedures agree well in elastic stage (strain range 0-0.5% assumed). But the slopes of the linearly fitted curves, i.e. the so-called dynamic Young’s moduli, are much different from the corresponding real values. The significant errors come from the non-uniformity of stress in specimen during the beginning stage of loading process. The results clarify that it is unfeasible to measure Young’s moduli by conventional SHB.

• Periodical: Applied Mechanics and Materials (Volumes 29-32)
• Pages: 68-71
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.29-32.68
• Online since: August 2010
• Authors: Yong Jian Mao, Yu Long Li, Rui Wang, Wei Guo Guo, Fei Fei Shi
• Keywords: Experiment, Finite Element Model (FEM), Split Hopkinson Bar, Young's Modulus

References

[1] H. Kolsky: Proc. Royal Society B Vol. 62 (1949), pp.676-700.

[2] L.L. Wang and Z.X. Zhu: Foundation of stress Waves. (National Defense Industry Press, Beijing, China, 2005).

[3] M.L. Xu, R.Q. Zhang and G.Y. Zhang: Explosive and Shock Waves Vol. 23, No. 3 (2003), pp.235-240.

[4] H. Meng and Q.M. Li: International Journal of Impact Engineering Vol. 28, No. 5 (2003), pp.537-555.

[5] L.M. Yang and V.P.W. Shim: International Journal of Impact Engineering Vol. 31, No. 2 (2005), pp.129-150.

[6] L. Song and S.S. Hu: Explosive and Shock Waves Vol. 25, No. 3 (2005), pp.207-216.

[7] Q. Wang, T. Wang, C.B. Yu and X.L. Wang: Earthquake Engineering and Engineering Vibration Vol. 26, No. 2 (2006), pp.92-95.

[8] W. Li, H.P. Xie and Q.Z. Wang: Journal of Experimental Mechanics Vol. 20, No. 2 (2005), pp.200-206.

[9] S.Y. Chen, C.G. Huang and Z.P. Duan: Explosive and Shock Waves Vol. 23, No. 4 (2003), pp.355-359.

[10] Y.J. Mao, Y.L. Li and F.F. Shi: Chinese Journal of Solid Mechanics. Vol. 29, No. 2 (2009), pp.170-176.
