Technical and Economic Analysis of 150MW Turbine Unit about Two Reconstruction Modes for High Back Pressure Heating

Abstract:

In this paper, the characteristics of two modes of high back pressure reconstruction techniques for 150 MW reheat turbine units were researched. One was reconstruction of double back pressure and double rotors and the other was one-off reconstruction of LP cylinder. The former redesigned for lower pressure(LP) rotors for running at high back pressure, and hydraulic coupling bolts adopted to achieve the switch of low pressure rotors that run at high and lower back pressures. The one-off reconstruction of LP cylinder has achieved the switch of static and dynamic blades between high and low pressure. The two reconstruction both realized heat supply on the high back pressure condition, utilized cold source loss and increased the unit efficiency. After reconstruction, the economic index under both normal back pressure condition and high back pressure heating condition have been obtained by performance test. Under the high back pressure heating condition, the unit heat rate reaches 3700-3800kJ/kW.h, and the thermal efficiency has achieved 95-97%.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 1708-1713
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.1708
• Online since: February 2013
• Authors: Jun Zhai Duan, Wei Zheng, Xue Dong Wang, Yu Zhen Hao
• Keywords: Circulating Water Heating, High Back Pressure Heating Supply, High Back Pressure Reconstruction, Turbine Units

References

[1] Fang Kao. Shandong Electric Power[J], 2010, 3: 46-48(In Chingese).

[2] Xiukun Zhang, Gang Zheng, Chuanwei Liu, et al. . Journal of Shanghai University of Electric Power[J], 2009, vol25(6): 543-546(In Chingese).

[3] Jie Zheng. . Energy Conservation Technology[J], Jul. 2006, No. 4: 380-382(In Chingese).

[4] Weiguang Zhao, Xinguo Li, Min Jiang., Northeast Electric Power [J], 2005, 10: 1-5(In Chingese).

[5] Min Fang, Lu Cong. . Journa l of Shenyang Institute of Engineering (Natural Science) [J], 2010, vol6(1): 10-12(In Chingese).

[6] Xuening Dong, ongchunLi H, Yushuang Guo. . Northeast Electric Power[J], 2005, 3: 5-8(In Chingese).

[7] Xiaohong Wang, Chao Sun. . Huadian Technology[J], 2009, vol31(1): 37-39(In Chingese).
