Research of Cable PD Detected Technology Based on Variable Frequency Oscillation Wave

Abstract:

With the accelerating construction of strong smart grid, and the grid voltage level rising, performance requirements for the electrical insulation of electrical equipment also continue to increase. The ( XLPE ) cable with good electrical and thermal performance and simple structure, the manufacturing cycle is short, safe and reliable power supply etc, which is widely used in power system ; Partial discharge is in the power cable to run a larger security risks is a sign of deterioration of the cable insulation is caused by insulation deterioration of important reasons . In this paper, based on variable frequency resonant damped oscillatory wave voltage XLPE cables and their connectors partial discharge site detection technology, the damped oscillatory wave voltage and power frequency voltage equivalent; the field test requirements, parameter optimization and performance detection impedance, and use advanced digital signal processing methods to analyze the test data processing, to provide a reference for the cables and their joints more accurately determine the insulation condition.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 2331-2333
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.2331
• Online since: February 2013
• Authors: Zong Xi Zhang
• Keywords: Detected Impedance, Oscillatory Wave, Partial Discharge (PD), XLPE Variable Frequency

References

[1] IEEE std -2001. IEEE Guide for Field Testing and Evaluation of the Insulation of Shielded Power Cable Systems. New York. (2002).

DOI: 10.1109/ieeestd.2002.93394

[2] IEEE Std -2004. IEEE Guide for Field Testing of Shielded Power Cable Systems Using Very Low Frequency (VLF). New York. (2005).

DOI: 10.1109/ieeestd.2005.95930

[3] Gulski E, Frank J, Johan J, et al. Advanced partial discharge diagnostic of MV power cable system using oscillating wave test system[J ]. IEEE Electrical Insulation Magazine, 2000, 2 (16) : 17-25.

DOI: 10.1109/57.833657

[4] E. Gulski, J.J. Smit, P.N. Seitz; PD Measurements On-site using Oscillating Wave test System, IEEE International Symposium on EI, Washington DC , USA June (1998).

DOI: 10.1109/elinsl.1998.694823

[5] F.J. Wester,E. Gulski J.J. Smit P.N. Seitz; Experiences from On-site PD Measurements using Oscillating Wave Test System; ISH 99 London August (1999).

DOI: 10.1049/cp:19990919

[6] F. Petzold PD diagnoses an MV cables with oscillating voltage CIRED Malaysia 2005 APA Conference.

[7] E. Gulski, F.J. Wester, J.J. Smit, B. Quak, O. Piepers, F. de Vries; Advanced Partial Discharges Data Analysis of Distribution Power Cables, CMD 2006, Korea.

[8] Uchida K, Tanaka H, Hirotsu K. Study on detection for the defects of XLPE cable lines[J]. IEEE Trans on PWRD, 1996, 2 (11) : 668.

DOI: 10.1109/61.489320

[9] E. Peschke. Spannungsp ruefung an kabelanlagen [J]. Elektrizitaetsw irtschaft, 1986, 85 (18) : 691～ 692.

[10] CIGREW G 21-09. After laying tests on high voltage extruded insulation cable system [J]. Electra, 1997, 173 (8) : 33～41.

[11] IEC 62067 Ed. 1, Power cables with extruded insulation and their accessories for rated voltages above 150 kV (Um = 170kV ) up to 500 kV (Um = 525 kV ) -Test methods and requirements, 2000[S ].

DOI: 10.3403/30078182
