Compensation of Phase Modulation Disturbance in All Fiber-Optical Current Transformer

Abstract:

In order to improve measurement accuracy of all fiber-optical current transformer (FOCT), an improved demodulation algorithm was proposed for a sine modulation. The formula for effective phase modulation depth (EPMD) was firstly presented, and three kinds of potential external disturbance in EPMD were analyzed. To overcome the current measurement error induced by these EPMD disturbances, we put forward an improved algorithm for time-dependent measurement of EPMD by second- and fourth-order harmonic component of optoelectronic signal. A simulation experiment in different disturbance intensity were carried out, and the results showed that when measured current is between 200A~1500A,the proposed algorithm can enhance the current measurement accuracy by over 30 times than the conventional algorithm, and measurement relative deviation can be maintained below 0.2% if the disturbance intensity is below 5%.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 2317-2321
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.2317
• Online since: February 2013
• Authors: Yun Han Luo, Li Jia Xia, Cheng Liang, Jian Hui Yu, Jun Zhang, Zhe Chen
• Keywords: Disturbance Compensation, Fiber-Optical Current Transformers, Modulation Phase, Signal Demodulation

References

[1] Perez-Millan F., Martinez-Leon Ll., Diez A., Cruz J. L. and Andres M. V., A Fiber-Optic Curre t Sensor With Frequency-Codified Output for High-Voltage Systems : IEEE Phot. Techn. Lett. Vol. 14 (2002), pp.1339-1341.

DOI: 10.1109/lpt.2002.801593

[2] Rose A. H., Etzel S. M. and K. B. Rochford, Optical Fiber Current Sensors in High Electric Field Environments : Journal of Lightwave Technology Vol. 17 (1999), pp.1042-1048.

DOI: 10.1109/50.769306

[3] Bohnert K., Gabus Philippe, Brandle H. and Guggenbach P., Fiber-optics dc current sensor for the electro-winning industry : Proc. of SPIE Vol. 5855 (2005), pp.210-213.

DOI: 10.1117/12.623794

[4] T. W. MacDougall, D.R. Lutz and R. A. Wandmacher, Development of a fiber optic current sensor for power systems : IEEE Trans. Power Deliv Vol. 7 (1992), pp.848-853.

DOI: 10.1109/61.127089

[5] ShayneX. Short, AlexandrA. Tselikov, Josiel U. de Arruda and James N, Blake Imperfect Quarter Wave-plate Compensation in Sagnac Interferometer-Type Current Sensors : Journal of lightwave technology Vol. 16(1999), pp.1173-1177.

DOI: 10.1109/50.701399

[6] CHEN C Y, CHEN Z and YU J H, Error tolerance of fiber quarter waveplate in fiber optic current transformer : Instrument Technique and Sensor, Vol. 5(2011) pp.12-14. (In Chinese).

DOI: 10.1166/sl.2012.2478

[7] Shayne X. S., U. de Arruda J., Tselikov A. A. and Blake N. J., Elimination of Birefringence Induced Scale Factor Errors in the In-line Sagnac Interferometer Current Sensor : Journal of Lightwave Technology, Vol. 16(1998) pp.1844-1850.

DOI: 10.1109/50.721071

[8] BOHNERT K., GABUS P. and NEHRING J., Temperature and vibration insensitive fiber-optic current sensor : Journal of Lightwave Technology, Vol. 20(2000) pp.267-276.

DOI: 10.1109/50.983241

[9] Lin H., Lin W. and Chen M., Modified in-line Saganc interferometer with passive demodulation technique for environmental immunity of a fiber-optic current sensor : Applied Optics Vol. 38(1999), pp.2760-2766.

DOI: 10.1364/ao.38.002760

[10] ZHAO J J, FENG L S and ZHANG C X, Optimum Design of Fiber Optical Current Sensor : Optical Technique. Vol. 31 (2005) pp.918-920. (In Chinese).
