Investigation of Temperature Field of the Canned Motor of Nuclear Primary Pump

Abstract:

The safe operation of canned motor in nuclear primary pump is very important for nuclear power station. Taken a 5500KW large canned motor of nuclear primary pump as an example, physical model of three dimensional fluid and temperature coupled field was established. The motor temperature distribution under nominal working condition was calculated by using finite volume method. By calculation, revealing the temperature distribution regularity of stator strands, rotor bars, stator core and rotor core, which have significant reference value to structure design of canned motor.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 547-550
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.547
• Online since: February 2013
• Authors: Shu Ye Ding, Fan Dong Meng
• Keywords: Finite Volume Method (FVM), Nuclear Power Station, Regularity, Structure Design, Temperature Distribution

References

[1] Lu Yiping, Zheng Guoli, Li Junting, et al．Uniformity of multi-path ventilation in rotor of air inner-cooled turbo generator[J]．Proceedings of the CSEE, 2010, 30(3): 99-104(in Chinese).

[2] Li Weili, Chen Yuhong, Huo Feiyang, et al．Fluid flow and temperature field analysis between two poles of a large air-cooled hydro-generator rotor in rotation [J]．Proceedings of the CSEE, 2012, 32(9): 132-139(in Chinese).

[3] Huo Feiyang, Li Yong, Li Weili, et al．Calculation and analysis on stator ventilation structure of different optimum proposal in air-cooled turbogenerator [J]．Proceedings of the CSEE, 2010, 30(6): 69-74(in Chinese).

[4] Yao Ruoping, Rao Fangquan．Analysis of 3D thermal field in the stator of large hydro-generator with evaporation-cooling system[J]．Proceedings of the CSEE, 2003, 23(6): 87-90(in Chinese).

DOI: 10.1109/iemdc.2003.1210348

[5] Ding Shuye, Ge Yunzhong, Chen Weijie, et al．Coupling calculation and analysis of three-dimensional temperature field for doubly-fed wind generator[J]．Electric Machines and Control, 2012, 16(3): 83-89(in Chinese).
