Design and Analysis of a Parallel Robot with Flexure Hinges for Target Alignment System

Abstract:

In this paper we present a parallel robot with flexure hinges for target alignment system of a high power laser facility. The robot contains a parallel mechanism with 6 DOF which has nanometer positioning accuracy and is driven by six linear actuators. We design a new flexure hinge which has higher accuracy, strong environmental suitability and simple structure compared with conventional flexure hinge which has backlash and friction issues. The kinematics analysis of the parallel mechanism is also discussed. The simulation analysis of the mechanism is done by ADAMS. The mechanism is proved meeting the design requirements by comparing the results of the theory analysis and the simulations.
