A Preamplifier-Latch Comparator with Reduced Delay Time for High Accuracy Switched-Capacitor Pipelined ADC

Abstract:

This paper presents a modified preamplifier-latch comparator for minimum latch delay and minimum input referred noise. The ratio of PMOS/NMOS in cross-coupled inverter is verified theoretically and optimized for minimum comparator delay. The cross-coupled load, the cascaded structure and the capacitor neutralization techniques are adopted to reduce the kickback noise and the input referred offset voltage. The comparator circuit is designed in a TSMC 0.35 um/3.3 V 2P4M CMOS process. Simulations show that the delay time of latch is declined by 18 percent after optimization and the maximum transfer delay time is only 384.5 ps. The peak to peak value of kickback noise is only 0.831uV in case of Vin,max=1.25 V, and the Monte Carlo simulation results show that equivalent input referred offset voltage is 4.56mV.

• Periodical: Applied Mechanics and Materials (Volumes 303-306)
• Pages: 1842-1848
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.303-306.1842
• Online since: February 2013
• Authors: Jin Rong Wu, Ying Ju, Zhi Lun Lin, Chu Lian Lin, Xiao Chao Li
• Keywords: Delay Time, Kickback Noise, Low Offset, Preamplifier-Latch Comparator

References

[1] B. Goll and H. Zimmermann: IEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS—II: EXPRESS BRIEFS Vol. 56 (2009), pp.810-814.

[2] P.E. Allen and D.R. Holberg: CMOS Analog Circuit Design 2nd (Publishing House of Electronics Industry, Beijing 2003).

[3] S. Devarajan and L. Singer: SOLID-STATE CIRCUITS Vol. 44(2009), pp.3305-3313.

[4] D. Li, D. Rennie, P. Chuang, D. Nairn and M. Sachdev: Design and Analysis of Metastable-Hardened and Soft-Error Tolerant High-Performance, Low-Power Flip-Flops. Int Symp Quality Electronic Design (ISQED), 2002 pp.1-8, (2011).

DOI: 10.1109/isqed.2011.5770787

[5] M.S. Baghini and M.P. Desai: Impact of Technology Scaling on Metastability Performance of CMOS Synchronizing Latches. Proceedings of the 15th International Conference on VLSI Design, pp.317-322, (2002).

DOI: 10.1109/aspdac.2002.994941

[6] Y. Jung, S. Lee, J. Chae and G.C. Temes: ELECTRONICS LETTERS Vol. 47(2011), pp.167-168.

[7] G. Van der Plas, S. Decoutere and S. Donnay: A 0. 16pJ/Conversion-Step 2. 5mW 1. 25GS/s 4b ADC in a 90nm Digital CMOS Process. IEEE Int. Conf. on Solid-State Circuits, 6-9 Feb, (2006).

DOI: 10.1109/isscc.2006.1696294

[8] G.A. Al-Rawi: A New Offset Measurement and Cancellation Technique for Dynamic Latches. Int Symp Circ and Syst, (2002).

[9] D-S, Khosrov: A New Offset Cancelled Latch Comparator for High-Speed, Low-Power ADCs. IEEE Asia Pacific Conference on Circuits and Systems, pp.13-16, (2010).

DOI: 10.1109/apccas.2010.5774892

[10] P.M. Figueiredo and J. C, Vital: Low kickback noise techniques for CMOS latched comparators. Int Symp Circ and Syst. Vancouver, Canada, (2004).

DOI: 10.1109/iscas.2004.1328250

[11] N. Weste and D. Harris: CMOS VLSI Design-A Circuits and Systems Perspective 3rd ( Addison-Wesley, Boston 2005).

[12] A. Nikoozadeh and B. Murmann: IEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS—II: EXPRESS BRIEFS Vol. 53(2006), pp.1398-1402.

DOI: 10.1109/tcsii.2006.883204

[13] T.W. Matthews and P.L. Heedley: A Simulation Method for Accurately Determining DC and Dynamic Offsets in Comparators. IEEE 48th Midwest Symposium on Circuits and Systems, USA, 7-10, Aug. Vol. 2, pp.1815-1818, (2005).

DOI: 10.1109/mwscas.2005.1594475

[14] K. Liu and Y.G. Yang: Semiconductors Vol. 29 (2008), No. 1, pp.75-81.

[15] Ning Ning, Qi Yu, et al. Microelectronics In Chinese Vol. 35 (2005), pp.56-58.
