Cable Elements for Numerical Analysis of Highline Cable System of Alongside Replenishment

Abstract:

Various of cable elements are used in the numerical analysis of cable structures. According to the mechanical characteristics of highline cable system of alongside replenishment at sea, two cable elements are investigated: catenary element, which is the exact solution, and parabolic element, which is the approximate solution but simpler to calculate. The equilibrium equations of each cable element are introduced, and the expressions of tangent stiffness matrix are derived. The tangent stiffness matrix of catenary element is calculated through Newton interactive method.

• Periodical: Applied Mechanics and Materials (Volumes 303-306)
• Pages: 2847-2850
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.303-306.2847
• Online since: February 2013
• Authors: Kai Wei, Liang Xin Zhang, Nan Li
• Keywords: Alongside Replenishment, Catenary Element, Highline Cable, Parabola Element

References

[1] LU Yongjin: Shipbuliding of China, 1996 (1): 17-22 (in Chinese).

[2] He Xuejun, Zhang Liangxin: ACTA PHYSICA SINICA, 2010, 59 (5): 3088-3092 (in Chinese).

[3] Knudson: Static and dynamic analysis of cable net structures. Doctoral dissertation, University of California, Berkely, California, (1971).

[4] Dong ming, Xia shaohua: Chinese J. Comp. Mech., 1997, 14(3): 268-275 (in Chinese).

[5] Yang Menggang, Chen Zhengqing: Engineering Mechanics, 2003, 20 (1): 42-47 (in Chinese).

[6] Jayaraman H. B, Knudson W. C: Comp. Struct., 1981, 14: 325-333.

[7] H. Max Irvine. Cable Structure[M]. Cambridge: The MIT Press, (1981).
