Representation of Asynchronous Motor Dynamics by Generalized Kloss Characteristics

Abstract:

The paper presents experimental results and mathematical modeling aimed to describe complex machine aggregates working under dynamic conditions. From parameters obtained experimentally the generalized Kloss characteristics is derived for nominal operational speeds of 1,450 min^-1, 1,000 min^-1 and 750 min^-1 under sinusoidal excitation. The steady-state motion is conveniently reinterpreted as an ellipse centered at the working point. Working point is given as the intersection of moment characteristics of the asynchronous motor with the loading characteristics of DC motor with separate excitation. The results of measurements show, that it is necessary to consider the linear dynamic characteristics especially for dynamic response computations near to the resonance.

• Periodical: Applied Mechanics and Materials (Volume 309)
• Pages: 113-120
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.309.113
• Online since: February 2013
• Authors: Eva Riečičiarová, Tibor Nánási
• Keywords: Asynchronous Motor, Critical Moment, Dynamic Characteristic, Dynamic Testing

References

[1] Mudrik, J., Naď, M. Principles of mechatronic modelling of machine aggregates. In Proceedings of International Conference Theory and Practice of Gear Drives and Transmissions, Iževsk, Russia, 2008, 27-32. (In Russian).

[2] Mudrik, J. - Lipták, N. - Naď, M. The effect of the speed-torque characteristics upon the steady-state motion of the machine aggregate. In Proceedings of the X. International Conference on the Theory of Machines and Mechanisms, Liberec, 2008, 417-422.

[3] Naď, M. Structural dynamic modification of vibrating systems. Applied and Computational Mechanics, 2007, 1, 203 – 214.

[4] Oravcová, J., Mudrik, J. Contribution to dynamics of machine aggregates containing gearing. Acta Mechanica Slovaca, TU Košice, 2008, 3, 317-324.

[5] Mudrik, J., Naď, M. Mechatronical approach to machine dynamics. In Proceedings of 10th International Symposium on Mechatronics. Alexander Dubček University of Trenčín, Trenčianske Teplice, 2007, 33-38.
