Jaw Crusher Based on Discrete Element Method

Abstract:

In order to analyze the force condition and crushing power of crusher teeth plate, the discrete element method models of jaw crusher and double-cavity jaw crusher are set up respectively using EDEM, a kind of software for discrete element analysis. Meanwhile, the working process, the loading force on the teeth plate and crushing power are simulated. The results show that: the rationality of the DEM simulation is declared, and the crushing process of the particles is also shown intuitively. The loading force condition and the crushing power of the moving jaw teeth plate serve as basis for its abrasion and energy consumption respectively.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 101-105
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.101
• Online since: February 2013
• Authors: Fu Sheng Mu, Hui Li, Xing Xue Li, Hong Zhi Xiong
• Keywords: Crushing Process, Discrete Element Method (DEM), Double-Cavity Jaw Crusher, Jaw Crusher

References

[1] Hu Guoming: Analysis and Simulation of Granular System by Discrete Element Method Using EDEM. Wuhan: Wuhan university of science and technology press, 2010,pp.233-280.

[2] Cleary P W: Recent Advances in DEM Modelling of tumbling Mills. Minerals Engineering, 2001,14(10),pp.1295-1319.

DOI: 10.1016/s0892-6875(01)00145-5

[3] Djordjevic N, Shi F N, Morrison R D: Applying Discrete Element Modelling to Vertical and Horizontal Shaft Impact Crushers. Minerals Engineering, 2003,16,pp.983-91.

DOI: 10.1016/j.mineng.2003.08.007

[4] Matthew R, Kuhn A: Grinding Table for Cement Milling. Engineering Computations, International Journal for Computer-Aided Engineering and Software. The Discrete Element Method: Numerical Modelling of Discontinua, 2004, Volume 21, Number 2/3/4.

[5] Gary W. Delaney, Paul W. Cleary, Matt D. Sinnott, Rob D. Morrison: Novel application of DEM to modelling comminution processes. Particles Science and Engineering, 2010,Vol.10 No.1:1-9.

DOI: 10.1088/1757-899x/10/1/012099

[6] Wang Guo-qiang, Hao Wanjun, Wang Jixin: Discrete element method and its application in the practice of EDEM. Xian: Northwestern university press, 2010,pp.16-19.

[7] Refahi, J. Aghazadeh Mohandesi, B. Rezai: Discrete Element Modelling for predicting breakage behavior and fracture energy of a single particle in a jaw crusher. International Journal of Mineral Processing, 94(2010),pp.83-91.

DOI: 10.1016/j.minpro.2009.12.002

[8] Mu Fusheng, Fan Yanhua: Double-cavity jaw crusher design. Metal mine, 2004 (9),pp.44-50.

[9] Luo Hongping, Chen Xiaoyun: Moving jaw plate and attrition analysis of compound pendulum jaw crusher. Guangxi engineering college journal, 2011 (4),pp.18-21.
