Optimization Design of Feeding Unit of the Forward Type Flute Laminating Machine

Abstract:

For paper forward unit of the current forward type flute laminating machine, the contact surface of the paper forward unit may damage paper during high speed paper forwarding. In view of this phenomenon, a solution is proposed through the study on the feeding unit of the flute laminating machine. In this paper, the corresponding sprocket driveshaft is controlled by a servo motor to slowly forward paper at the beginning and accelerate its forwarding speed gradually, until the entire feeding process is completed. In this way, the problem of paper pile-up and damages during the paper forwarding process can be solved, while matching backing paper feeding, so as to improve the feeding accuracy of the full-automatic flute laminating machine and hence its laminating accuracy.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 106-109
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.106
• Online since: February 2013
• Authors: Run Xie, Ji Fei Cai, Jia Cong Chen
• Keywords: Feeding Unit of the Paper Forward Unit, Full-Automatic Flute Laminating Machine, Servo Motor, Sprocket Driveshaft

References

[1] Li Hang et al. Stress Analysis of the Paper in the Glue Lamination Unit of Flute Laminating Machine and Optimization Design of Roller Distribution [J]. Packaging Engineering, 2007.12:73-76.

[2] Liu Yixiong. A Long Way to Go: Current Status and Development of China's Post-press Machinery [J]. Print Today, 2009.4:43 -44.

[3] Pu Lianggui. Mechanical Design [M]. Higher Education Press, 2006.

[4] How to Select the Type of Servo Motor [Z].

[5] Materials of Panasonic A5 Servo Motor Selection [Z]. P74 .
