Stator Temperature Distribution of AC Machine Based on Fluid Flow Field

Abstract:

In order to study the impacts of the stator ventilation structure on the thermal performance, the fluid flow model of the stator radial ventilation ducts is established. The fluid flow fields are calculated and analyzed, from which the three-dimensional fluid field distribution inside the radial ventilation ducts is shown. Subsequently, the heat transfer coefficients are obtained on the basis of calculated results of the fluid flow field, and the stator three-dimensional temperature fields are solved. The numerical results are compared among different inlet velocities at the entrance of the radial ventilation ducts, which provides a theory basis for the design of the cooling system and improves the safe operation level of the generator.

• Periodical: Applied Mechanics and Materials (Volumes 313-314)
• Pages: 27-30
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.313-314.27
• Online since: March 2013
• Authors: Cong Hui Huang, Xin Zhen Wu
• Keywords: AC Machine, Finite Element Method (FEM), Finite Volume Method (FVM), Fluid Field, Temperature Field

References

[1] A. F. Heat: Flow in the stator core of large turbine generators by the method of three-dimensional finite elements. PartⅠ: analysis by scalar potential formulation; Part Ⅱ: temperature distribution in the stator iron. IEEE Trans. on PAS, Vol.95, No.5(1976), pp.1648-1668.

DOI: 10.1109/t-pas.1976.32265

[2] M. S. Rajagopal, et al.: Finite element analysis of radial cooled rotating electrical machines. International Journal of Numerical Methods for Heat & Fluid Flow, Vol.9, No.1(1999), pp.18-38.

DOI: 10.1108/09615539910251086

[3] Yiping Lu: Fluid Flow and Temperature Field Simulation of Rotor of Large Turbo-generator with Air Coolant. Post-doctor Report, Harbin Science and Technology University(2007).

[4] J. P. Holman: Heat Transfer, McGraw-Hill Education(2011)

[5] Shunnian, Ding: Cooling of Large Motors, Beijing: Machinery Industry Press(1983).
