The Design and Implementation of Micromouse Based on C8051F120

Abstract:

According to the international Micromouse competition requirements suited for the IEEE standard maze, a kind of Micromouse based on C8051F120 is designed in this paper. The hardware structure and software algorithm are specifically introduced, the Center Toward Rule and the Bellman-Ford Algorithm is used for turning, searching and attitude control is optically designed. The designed Micromouse can find the optimal route of the IEEE standard maze by 0.4 s and walk rapidly and stably.

• Periodical: Applied Mechanics and Materials (Volumes 313-314)
• Pages: 308-311
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.313-314.308
• Online since: March 2013
• Authors: Dong Wan
• Keywords: BFA, C8051F120, CTR, IEEE Standard Maze, Micro-Mouse

References

[1] Zhou Ligong. The Design Guide for IEEE Micromouse. Guangzhou Zhiyuan Electrical Corporation(2008).

[2] Xia Yan. Design and Implementation of Micromouse Based on ARM7. Coal Technology(2010).

[3] Zhu Shan, Fu Huozhe, Wu Zhongli. Research and realization on micromouse for maze searching. Microcomputer Applications(2008).

[4] Xu Shoujiang. Labyrinth algorithm. China Computer & Communication(2009)．

[5] Zhu Wenda. Maze Search Algorithm Research of IEEE Maze Micromouse. China Science and Technology Review(2009).

[6] Wang Bin, Zhang Weigang. Intelligent Algorithm Research of Micromouse Maze Based on IEEE Standard. Electronic Design Engineering(2011)．

[7] YangXin. Research and Realization on Micromouse for Maze Searching in Coalmine.Coal Technology(2010).

[8] Zhang Xinyi. An Algorithm of Micromouse Maze. Microcontrollers & Embedded System (2007).

[9] Cai Zixing. Robotics. Beijing: Tsinghua University Press(2000).
