The New Rotary Steering Drilling Tool and Blind Area Borehole Trajectory Spline Curve Predicting Method

Abstract:

This paper put forward the overall index of the new point-to-bit type rotary steering drilling tool. It briefly researched the steering mechanism mechanics model (composite beam) and the new point-to-bit type rotary steering drilling tool structure. Based on this fact, it proposes the spline curve prediction blind area trajectory method aim at the blind area existed at the small area of the front end of the drill. The paper discussed the forecast results and probe some laws: as the well depth changes, the inclination of the well path increases, and the azimuth of the well path changes slowly; when the drill build-up rate increases, the inclination angle of the well path increases.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 225-230
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.225
• Online since: May 2013
• Authors: Fu Dong Xu, He Lin Xu, Bei Zhuang Hua, Han Xing Li, Ding Feng
• Keywords: Borehole Trajectory, New Rotary Steering Drilling Tool, Predicting Method, Spline Curve

References

[1] ZhangShaoHuai. Modern steering drilling of new developments in technology and development direction [J]. Journal of oil, 2003, (3) : P22~86.

[2] WangQingJiang, MaoJianHua, wang li. Directional well borehole trajectory prediction and control technology [J]. J gas technology, 2008, 31 (4) : P150~152.

[3] ZhuXiaoHua etc. The hole trajectory prediction theory and method research. Natural gas industry, 2004, (4) : P38~40.

[4] the LiuXiuShan. Hole track geometry. Petroleum industry press. 2006.12.
