Experimental Analogy Method for Measuring S-Wave Slowness of Low Porosity and Low Permeability Reservoir

Abstract:

Fracturing technology is one of the most efficient ways to productivity evaluation, and the key of fracturing technology is how to describe rock mechanical behaviors to which S-wave slowness is an important parameter. According to the complexities of low porosity and low permeability of Pucheng oilfield, we designed and obtained the experimental scheme for measuring the velocities of P-wave and S-wave. The samples are focus on dry sample and rock with water saturation 100%, 80%, 60% and 40% respectively, under two conditions at normal temperature with 5MPa and with formation pressure at 90°C. By conducting triaxial test, the velocities of P-wave and S-wave under different temperatures and different pressures were obtained. On the analysis of 26 groups of data, the results showed that on the formation condition, S-wave slowness value varied linearly with water saturation, and S-wave slowness was also linear to P-wave slowness at different water saturation. Oil-bearing layer and water layer models were created separately, to compute S-wave through P-wave based on linear interpolation. We validated the new approach with an example from real array acoustic log data of Pushen 18 well. The results demonstrated the advantages of this method over empirical equation proposed by Entwisle’s and Dreiser Company. The relative error from them compared with log data are more than 10% whereas that of our method is 4.2%.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 385-389
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.385
• Online since: May 2013
• Authors: Zhong Hao Wang, Fei Li Qin
• Keywords: Core Experiment, Core Sample, Pore Structure, P-Wave, Saturation, S-Wave

References

[1] Boit M A, Theory of Propagation of Elastic Waves in a Fluid Saturated Porous Solid. I. Low-Frequency Range, submitted to Journal of Acoustical Society of America. 1956. 28(2), pp.168-178

DOI: 10.1121/1.1908239

[2] Mavko G and Nur A. Wave propagation in partially saturated rocks, submitted to Geophysics 1979, 44: pp.161-178

DOI: 10.1190/1.1440958

[3] De-hua Han, et al. in: Recent advances and developments in rockphysics, elastic wave propagation in rocks, collections of geophysical technology, Stanford Rockphysics Borehole. edtied by Geophysics Project, 1987,7

[4] White J E, Biot-Gardner theory of extensional waves in porous rods, submitted to Geophysics. 1986, 51(3): pp.742-745

DOI: 10.1190/1.1442126

[5] Cheng C H and Toksoz M N, Elastic wave Propagation in a borehole, submitted to Geophysics. 1981. 46: 1706~1720

[6] Shi G and Shen L D, Studies on rock acoustic characteristics and features of anisotropic glutenite reservoir, submitted to Chinese Geophysical Society Annual. 1995. (in Chinese).

[7] Chu Z H, Liu Z P, Chen F, et al, Estimation of formation V_s, submitted to Well logging technology. 1995. 19(5):p.313~318. (in Chinese).

[8] Chu Z H, Xie J Z and Wang S X, Survey on the Acoustic Dispersion in Shaly Sandstone, submitted to Chinese Geophysical Society Annual. 1998. (in Chinese).

[9] Zhang C G, Jiang W Z, Xiao C W, et al. On methods of gas-formation indication by using acoustic full waveform log data, submitted to Well logging technology. 2004. 28(5): p.397~401. (in Chinese).

[10] Entwisle D C and McCann D M. Assessment of the use of Christensen's equation for the prediction of shear wave velocity and engineering parameters, submitted to Geological Society Special Publication. 1990. 48(1): p.347~354

DOI: 10.1144/gsl.sp.1990.048.01.29
